NM500 Wear Resistant Steel Plate
NM500 Wear Resistant Plateis are one kind f wear resistant steel plate, we can also call it NM500 abrasion resistant plate. It is under the standard of GB 24186 with a hardness range of 470-540 HBW. Houming also provide other wear resistant steel plate like NM360, NM400, NM450, and also ship build steel, weathering steel plate, stainless steel plate ect.
What the NM500 mean?
- "NM" indicate the abbreviation of Chinese Pinyin "Naimo", it means the wear resistant;
- "500" means the garde level
NM500 Wear Resistant Steel Sheet Product advantange:
- High abrasion resistance
- Excellent perfomance of compression resistance, this advantange helps it improve the lifetime of equipment, and saving cost for you.
- High mechanical strength, NM 500's strength is more than 3 times that of ordinary low alloy steel plates
Produt application:NM500 wear resistant steel plate is mainly used for where resistance to abrasion is a key concern, such as environmental protection machinery,abrasives, mining equipment, construction industry machinery, and other heavy-duty industries.
Chemical content:
Grade |
C |
Si |
Mn |
P |
S |
Ti |
Cr |
Mo |
Als |
B |
NM 500 |
0.38 max |
0.70 max |
1.70 max |
0.020 max |
0.010 max |
0.05 max |
1.20 max |
0.65 max |
0.01 max |
0.005-0.006 |
Mechanical properties:
Grade |
Yield strength Mpa |
Tensile strength Mpa |
Elongation |
NM 500 |
/ |
/ |
24 min |
Grade |
Thickness |
Hardness (HB) |
NM 500 |
70 mm max |
420~480 |
70-100mm |
450~540 |
Equivalent Steel grade:
GBT 24186 |
JFE |
SUMITOMO |
K500 |
SSAB |
NM 500 |
JFE-EH500 |
K500 |
500V |
Hardox500 |
Houming processing technique:
1. Environmently electric furnace steel producing;
2. Vacuum Treatment, which can remove extra elements such as carbon, hydrogen, oxygen, and nitrogen from the molten steel;
3. We have continuous casting and rolling system
4. accelerate cooling system, which can enhance the ferrite nuleation rate;
5. Ware-in- house inspection, you can appoint any third party or stuff to inspect qulaity.
