S275J0 Low alloy High strength steel plate
S275J0 low alloy high strength steel plate (S275J0 Low Alloy Steel Plate) is a Europen standard under EN 10025. S275J0 is mainly composed of iron, carbon, manganese, silicon, phosphorus and sulfur. Among them, carbon is the main reinforcing element of steel, which can improve the hardness and strength of steel, manganese and silicon can improve the toughness and corrosion resistance of steel, while the content of phosphorus and sulfur needs to be controlled within a certain range to ensure the quality and performance of steel.

S275J0 low alloy high strength steel plate grade indication:
  • S:  means a structure steel
  • 235: means the yield strength of the lower limit value: 235Mpa
  • J0: means the steel plate to do 0 ℃ impact work test
Chemial content:
  C Mn P S Cr Ni Cu Mo N
S275J0 (thickness 150mm max) 0.18 1.5 0.03 0.03 0.29 0.42 0.55 0.11 0.012
S275J0 (thickness 150mm min) 0.20 1.5 0.03 0.03 0.19 0.42 0.55 0.11 0.012

Mechanical properties:

 Yield Strength (≥ MPa); Dia. (d) mm d≤16 16< d ≤40 40< d ≤63 63< d ≤80     80< d ≤100 100< d ≤150 150< d ≤200 200< d ≤250
S275J0 (1.0143) 275 265 255 245 235 225 215 205



Tensile Strength (≥ MPa) d<3 3 ≤ d ≤ 100 100 < d ≤ 150 150 < d ≤ 250
S275J0 (1.0143) 430-580 410-560 400-540 380-540



Cooperative partner:

cooperative


Except S275, we also provide A633, A656 low alloy high strength steel plate and ship steel plate, corten steel plate, carbon steel plate etc.
