Product details

Special flash dryer for fermented soybean meal,Flash Dryer for Organic Pigments,Continuous Drying Equipment Flash Evaporation Dryer,SXG Series Industrial Spin Flash Dryer,Spin Flash Dryer Machine for Continuous Drying,Manganese Spin Flash Dryer,Excellent Quality Airflow Type Spin Flash Dryer,Revolving Flash colloided silica Dryer,Flash Dryer Drying

Applications

SXG Spin flash dryers are windly applied into Agrochemicals and Pesticide, such as Padan, Monosultap, ABamectin, Pyridaben, Paclobutrazol, Methomyl, Tricyclazole, Atrazine, etc. The performance of this spin flash dryer reaches international advanced level, with its high efficency, compact design, cheap price, our rotary flash dryer is warmly welcome by home and abroad users.

Features
1. SXG flash dryer equips a special cooling device at the bottom, thus effectively avoiding material deterioration due to high temperature.
2. Material fineness and final moisture content are adjustable.
3. Compared to other drying methods, flash dryer can greatly increase the proportion of materials

4. Reduced material residence time can effectively prevent the materials from sticking to walls of the drum, resulting in higher efficiency.

Technical Specifications of Flash Dryer, Flash Drying Machine

Model	Container diameter mm	Main dimensions mm	Power kw	Air volume m3/h	Water evaporation kg/h	Floor space m2
SXG-2	200	300×2800	0.75 ~ 2.2	300 ~ 800	10 ~ 20	3.5×2.5
SXG-3	300	400×3300	3 ~ 4	600 ~ 1500	20 ~ 50	3.8×2.7
SXG-4	400	500×3500	4 ~ 7.5	1250 ~ 2500	25 ~ 70	4×3
SXG-5	500	600×4000	5.5 ~ 11	1500 ~ 4000	30 ~ 100	4.2×3.2
SXG-6	600	700×4200	7.5 ~ 18.5	2500 ~ 5000	40 ~ 200	4.25×3.25
SXG-8	800	900×4600	11 ~ 18.5	3000 ~ 8000	60 ~ 300	4.5×3.5
SXG-10	1000	1100×5000	15 ~ 30	5000 ~ 12500	100 ~ 480	4.75×3.75
SXG-12	1200	1300×5200	15 ~ 37	10000 ~ 20000	150 ~ 745	5×4
SXG-14	1400	1500×5400	30 ~ 55	14000 ~ 27000	200 ~ 960	5.25×4.25
SXG-16	1600	1700×6000	45 ~ 75	18700 ~ 36000	250 ~ 7303	5.5×4.5

Our Services
Pre-sale service
Act as a good adviser and assistant of clients to enable them get rich and generous returns on their investments.
1. Introduce the product to the customer in detail, answer the question raised by customer carefully;

2.Make plans for choice according to the needs and special requirements of users in different sectors;

Sale service
1. Ensure product with high quality and pre-commissioning before delivery;
2. Delivery on time;

3.Provide full set of documents as customer`s requirements.

After-sale service
Provide considerate services to minimize clients` worries.
1.Assist clients to prepare for the first construction scheme;
2.Install and debug the equipment;
3.Train the first-line operators;
4. Examine the equipment;
5.Take initiative to eliminate the troubles rapidly;
6.Provide technical support;
7.Establish long-term and friendly relationship.

Service commitment
1. Provide clients one-year warranty to make sure the machine work well;
2.We always keep certain inventory level of spare parts, which means the replacements can be sent to you timely;
3.Send every client a preferential quotation.
