Product details

DEGOsilent Plus+
SEAMLESS SMOOTH FINISHED ACOUSTIC WALL AND CEILING
DEGOsilent Plus+ seamless mineral wool boards is a pure and simple seamless ceiling system.

Overall large area fusion with concealed metal grid .Smooth mineral wool boards application in interior ceiling and wall surfaces.

Fiberglass boards with acoustic coatings are the most finely finished acoustic plaster finish available.
DEGOsilent Plus+ Mineral Wool Acoustic Plaster consists of two components,The base material is fireproof safe and sound-absorbing minera wool panels(Rock wool or glass wool)

and sound absorption coating layer. thickness of 25 30 40mm ,By special washers Screws and adhesives , fixed mineral wool acoustic panels is on gypsumm board or cement construction mixes face.
DEGOsilent Plus+ face coating is a high quality inorganic dry powder ,mainly of recycled Natural inorganic mineral powder and air-purifying zeolite.sprayed at the project site,
The panels covered by acoustic plaster are available in a wide range of colours, from smooth to coarse-grained,Provided with 2-3mm thick plaster layer
Degosilent Plus+Super smooth acoustic ceiling system can effectively attenuate high, medium and low sound frequencies to optimize room acoustics , NRC 0.95(class A)
The thermal insulating property of prevents energy from leaking to oher parts of the building.
BENEFITS
• Seamless overall large-area sound absorption system
• Good fire resistance, building material combustion class A2.
•Can be used in the shape of curves and arches on the streamline transition.
• Reflectivity (LR0.86), reduce energy and electricity cost by 18%
• Inorganic dry powdertechnology coatings ， voc0.04%
• Extra strong sound absorption function, NRC 0.95
• 15-year limited quality guarantee

Description

Degosilent Acoustic Plaster This is a high-quality plastering acoustiac ceiling &wall system that absorbs unwanted noise from your space. Along with providing a more flexible alternative to traditional solutions, it can be applied to virtually any surface, making it perfect for curved walls, dramatic angles and arches. The solution comes in two variations: the Plus+ and the PLUS. The Plus+ has an ultra-smooth, fine-grain finish, whereas the Puls gives a smooth, medium-grain finish. Both solutions have a choice of finishes from fine texture to trowelled and smooth. They are available in a vast range of colours, so they can be tailored to your design requirements and can be installed at either 25mm class B or 40mm class A.

Configuration

Degosilent® PLUS produces two types of acoustic plaster systems:
* PLUS which a smooth finish;
* PLUS + which offers an ultra-smooth finish.

* ALUS + which offers fine-grain finish
Both systems can be applied on ceilings or walls as follows:
* directly onto a mineral wool layer fixed to a plasterboard, concrete or timber substrate;
* directly on a metal frame drywall system (typically 400mm), or;* as a spray onto a plasterboard or concrete substrate.

Degosilent® PLUS systems are generally made with a thick backing layer of mineral wool (main sound absorber) with one or two Degosilent® plaster
finish layers applied to it. In this configuration, the thicknesses available range from 20 mm to 40 mm.
plasters can also be used as sprays with a thickness of 3 mm.
Sound absorption
The sound absorption performances of Degosilen® acoustic plaster systems can achieve Class B or Class A absorption.

Reaction to fire
Degosilent® PLUS acoustic have a fire classification of A2-s1, d0 ( EN 13501-1).
Mold and humidity resistant
All Degosilent® products mold and humidity resistant.
Colors and shapes
Colors are open to design the products can be curved to follow a certain ceiling or wall shape.

Product Data Sheet

Materials	Acoustic coating (paste, already mixed)	Fireproof	A2-S1d0 En1350-1
Face	Ultra smooth，Granules，	Standard colours	RAL 9016 /NCS S300
Size	1200X600，1200X1200，1200X2400MM	Sound absorption	NRC0.85-0.95
Thick	25 30 40MM	painting thick	2-3MM
Fixing	Mechanical gaskets with screws, adhesives.	Suspension	Metal keel with plasterboard, metal grid direct, concrete direct
