Fully Automatic Screw rolling machineModel Z28-80
The machine is thread rolling machine automatic ZP28-15 enjoy strongly strcture,manufacture sophisticated,easily maintenance,reasonable price ect. Welcomed by the users.the machine could process radial but also axial machining process,also can processed bolts,special bolts,screw rod by change the thread roller.
Technical parameters:
Pressure of Roller max. |
150KN |
Rotary Speed of Main Shaft |
36,47,60,78(r/min) |
Working Dia |
4-48mm |
Feed Speed of Movable shaft |
5mm/s |
OD of Roller |
120-170mm |
Thread Length |
(no limits) |
BD of Roller |
54mm |
Main Power |
4kw |
Roller Width max |
100mm |
Hydraulic Power |
2.2kw |
Dip Angle of Main Shaft |
±5° |
Weight |
1700kg |
Center Distance of Main shaft |
120-240mm |
Size |
1480×1330×1440mm |
Pictures of machine:
Company information:
YINGYEE MACHINERY AND TECHNOLOGY SERVICE CO.,LTD
YINGYEE is the manufacturer specialized in various cold forming machineries and automatic production lines. We have a wonderful team with highly technology and excellent sales, which offer professional products and related service. We paid attention to quantity and after service, got great feedback and honor formal the clients. We have a great team for after service. We have sent several patch after service team to oversea to finish the products installation and adjustment.
Our products were sold to more than 20 countries already. Also included US and Germany.
Main product :
FAQ:
Training and Installation :
1 We offer installation service local in paid, reasonable charge.
2 QT test is welcome and professional.
3. manual and using guide is optional if no visiting and no installation.
Certification and after service:
1. Match the technology standard, ISO producing certification
2. CE certification
3. 12 months warranty since the delivery. Board.
Our advantage:
1. Short delivery period
2. Effective communication
3. Interface customized.
