System characteristics
Profile system:
National standard 6063-T5 can be used, according to customer needs, some components use 6063-T6 material to achieve higher strength and more stable requirements.
Hardware system:
Glass fans can use hidden hinges, yarn fans and guardrail can be equipped with European standard slot hardware system: hardware accessories, mature standard processing technology, quick positioning, adjustable quick mounting friction hinges and lock point lock seat, Double anti-misoperation to avoid damage to hardware accessories.
Sealing system:
Frame fan can use 30mm multi-cavity PA66 nylon heat insulation strip, automotive grade foam sealing system: rubber strip seal better, longer life, improve the overall sound insulation performance of the window.
Glass system:
Automotive grade double-layer hollow tempering process (6+12A+6), one bent hollow aluminum strip with internal molecular sieve, hollow layer filled with argon, sound insulation performance can reach 35~40 dB.
Accessory system:
1. Frame splicing and opening fan using 45 degrees splicing, group corner code splicing, improve the overall performance.
2. The bevelled line is simple and atmospheric, and the installation design is tight, the connection is stable, the wind pressure is high, and the overall performance is improved. (The square line is optional)
3. The yarn fan adopts 304 diamond mesh, and the window Angle adopts embedded rounded corner technology to prevent sharp Angle injury.
4. The outer frame and the glass fan add anti-fall rope to prevent the hinge damage and cause the glass fan to fall.
5. Add dust strips to the notch to prevent the accumulation of dust and garbage and look beautiful.
Advantages of this product
1. A variety of surface treatment methods, spraying, fluorocarbon, electrophoresis, porcelain swimming, wood grain to provide customers with a comprehensive profile surface treatment.
2. The bridge energy-saving design, the outer frame can be replaced by a multi-cavity structure outer frame, enhance the heat insulation performance, the secondary frame and the fan material to add a third seal, good sealing, watertight, sound insulation performance to meet the requirements of energy saving and emission reduction.
3. Adopting floor drain drainage to improve drainage capacity and prevent backfilling.
4. The built-in sub-frame installation method improves the stability of the overall window type. The sub-frame is used to make the overall window type flush, the yarn fan is opened inside and the glass fan is opened outside, which is easy to process, operate, disassemble and wash, and the service life is long.
5. Window screen integrated structure, improve the overall resistance, high temperature flame retardant, anti-theft and anti-mosquito, easy to clean.
We also have many related Aluminum Extruded Profile, aluminum furnitures,aluminum window and door profiles etc. Click on the keyword to enter the relevant page.
If you are interested in the product, contact 2bvideo.com for more information for more information
