High precision HSK63F ER32 collet chuck HSK63F-ER32-70L mill holder G2.5 Balanced Woodworking CNC Tool Holders
We are Pingyuan Best Machine Tools., Co., Ltd., the high-end cnc machine tools manufacturer and supplier from China. Our products line is over 100 models, mainly include: Collet Chuck , Tool Holder Device , Collet , Spanner , Pull Stud and Nuts Etc. Collet chuck also include many standards and models like: ISO series, BT30 series, BT40 series, HSK series, NBT series and CAT series, etc. HSK63F-ER32-70L Nickeled Coated Tool Holder belong to HSK series holder.
Product Description
|
Brand Name |
BESTMYT |
|
Model Number |
HSK63F-ER32-70 Coated Tool Holder |
|
Color |
Bright Silver White with Nickel coated process |
|
Materials |
20 CrMnTi Alloyed case hardened steel,black-finished and precisely grind. |
|
Taper tolerance |
<AT3 |
|
Precision |
0.002mm |
|
Surface Roughness |
>0.8mm |
|
Roundness |
<0.8μm |
|
Carbonizing depth |
>0.8mm |
|
Hardness |
HRC58-62 |
|
Dynamic Balance |
G 2.5 24000rpm |
|
Quality control |
100% inspection |
|
Warranty |
3 years |
|
Service |
Customized OEM / ODM |
|
Usage |
Suitable for working on drill, lathe,boring machine,milling machine and CNC machine center etc. |
|
Applicable cutters |
vertical disc cutter, sets of type of milling cutter, face milling cutter, milling cutter, three face milling cutter, Mechanical spindle and cutting tools and other accessories. |
1. Collet and replacment of cutting tools, screw nut and body must be clean,and add grease,otherwise it will damage the thread.
2.The device must be placed when the collet nut,and then into the tool,then the lock body.
3.The placement tool collet hole,clamping collet must exceed effective length,to avoid improper locking damage.
