Product details

Product Description

CIP Cleaning in Place CIP tank cleaning Stainless Steel System Unit Automatic Washing CIP Cleaning System mill supply

CIP Cleaning in Place is a new and effective cleaning technology widely used in dairy plants as well as beer, beverage, coffee,
sugar, pharmaceutical and other industries.Clean-in-place technology is a technology where the equipment is cleaned in situ
without the need to disassemble equipment, pipes, valves, etc. It has the following features:

1) local cleaning, easy to operate,

work safety, low labor intensity, high work efficiency.

2) thorough cleaning, and can simultaneously achieve the purpose of
disinfection and sterilization, to ensure health requirements, is conducive to product quality improvement.

3) cleaning Road, can
account for less workshop area.

4) detergent can be recycled, high utilization, steam and water are also more savings.

5) less wearing parts, the device has a long service life.

6) suitable for large, medium and small types of equipment cleaning.

7)cleaning work can be programmed and automated.

Step	Working process	Cleaning media	Cleaning time	Clean temperature
1	Pre-wash	Water	3-5Min	Normal temperature
2	Alkali wash	Alkali water (content 1-3%)	10-20Min	60-75℃
3	Middle wash	Water	3-10Min	Normal temperature
4	Acid wash	Acid water (content 1-2%)	10-20Min	60-75℃
5	Water wash	Water	3-10Min	Normal temperature
6	Disinfect before working	Hot-water	15-30Min	92-95℃

Details Images

Manufacturing Technique

1	Temperature measurement	3	0-100 degrees Celsius	Digital Far EasTone	Japan Fuji
2	Magnetic flap level gauge	4	800mm	With high, low level switch	Shanghai yunhe
3	Pneumatic valve	17	2inch	Acid and alkali	Shanghai Lino
4	Pneumatic valve	4	2inch	Steam	Shanghai Lino
5	NaOHLye Analyzer	1	0-10% The concentration of analysis	In the installation	METTLER TOLEDO, Switzerland
6	Nitrate concentration analysis	1	0-10% concentration of analysis	In the installation	METTLER TOLEDO, Switzerland

Company Profile

Wenzhou Suote Pharmaceutical and Chemical Engineering Co., Ltd.

We are high—tech enterprise specialized in design，manufacturing and installation of Pharmaceutical equipment, biochemical equipment，dairy and food equipment, environmental protection equipment，sanitary fluid pumps＆valves and etc.

Certifications

Exhibition

National Pharmaceutical Machinery Expo and China International Pharmaceutical Machinery Expo

The 55th (Spring 2018) National Pharmaceutical Machinery Expo and China International Pharmaceutical Machinery Expo were held from
April 20 to April 22, 2018 at the Chongqing International Expo Center.

Wenzhou Sote is inviting to invite the Fuzhou Strait International Exhibition

The 52nd (Fall 2016) National Pharmaceutical Machinery Expo and China International Pharmaceutical Machinery Expo were held from
November 5th to November 8th, 2016 at the Fuzhou Strait International Convention and Exhibition Center.

FAQ

Q: Are you manufacturer or trading company?

A: Suote is a professional manufacturer begin at 1998，have 22 years experence on Medicine, Food, Beverage, Dairy and Beer production machinery industrial.

Q:.Q: Where is your factory located?

A:We got three plant in Zhejiang Province, and Jiangsu Province and Fujian province,supply all kind of Stainess steel product.15 Minute driving to Wenzhou Airport. 1 hour to Shanghai ,1.5 hours to Guangzhou and shenzhen 2 hours to Beijing city.

Q:How could we confirm the details of the products?

A: we can discuss detaols by alibaba online trade manager ,wechat ,mail or whatspp ,skype.etc...

Q:Will you charge us for drafting if we have special requests?

A: the drafting drawing is free charge ,please fell free to contact us for any project.

Q: How long the warranty will be?
A: 1 Year warranty.

Q: How about the installation? And what if the machine not working well?
A: Yes, we will do that. There are two options:
a. We could appoint our engineer to your company to debug and repair, as for the cost of this trip such as
ticket, visa, accommodation and labor cost shall be on your side.
b. On-line service will be provided. If still under guarantee period, the necessary accessories and parts
will be provided free, but the transportation cost of it shall be on you side.

Q: Do you take L/C?
A: Yes, we accept Western Union, T/T and irrevocable L/C payable.better if we can act alibaba online insurance order.

Q. What is your terms of packing?
A: Generally, we pack our goods in plywood case or carton package for small parts.
If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.

Q. What is your terms of payment?
A: T/T in advance, 30% as deposit, and finish 70% balance payment before delivery.
We'll show you the photos of the products and packages before you pay the balance.

Q. What is your terms of delivery?
A: EXW, FOB, CIF, DDU.

Q. How about your delivery time?
A: Generally, it will take 3 to 4 weeks after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.

Q. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings.

Q.Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery

Q: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.

Q: Can we become your distributor in our country?
A: Yes, we very welcome you! More details will be discussed if you are interested in being our agent.
