The semi-automatic radiator core builder is used for assembling automobile radiator cores. The main feature of core building machine is distributing the tubes by manual, simple operation and easy adjustment. Compared with the full- automatic core assembly machine, semi-automatic radiator core builder cancels the complex automatic distribution tube device and flaring device, so the semi-automatic radiator core builder is simple, easy operation and high cost performance. Meanwhile, the core assembly machine may automatically install the header plates which greatly improve the production efficiency.
Technical parameters of radiator core builder
No.
Item
Data
1
Distance between
header plates (core length)
330 - 950mm
2
Distance between
side plates (core height)
300 -750mm
3
Thickness of
radiator core
16~ 60mm
4
Fin height
8mm, Customizable
5
Flat tube thickness
2mm
6
Spacing distance between
tubes
10mm
7
Compressed Air
0.4~0.6MPa
8
Machine power
380V 50Hz 15A
Customizable
