Product Information:
Product Name: Automatic Open Cam&Direct Bottom&Single Plate Paper Cup Machine
MODEL NUMBER : LXP -80
TYPE : 2- 14 OZ
APPLCATION : PAPER CUP PRODUCING
Product Features: Automatic Open Cam High Speed Paper Cup Machine
OPEN CAM SYSTEM
High efficiencyStable running
LXP-80 automatic medium-speed paper cup forming machine use table style, To separate mould system from transmit system ,the transmission parts are set inside of machine body which under the table.
The machine are combined with
1. whole body structure under automatic spray lubrication system;
2.open cam system;
3.Vertical shaft transmission system;
4.gear system.
All moulds are set-up the table ,which are easy for operation .
LXP-80 paper cup forming machine use open cam system and single aluminium plate ,which make machine more faster and smaller .And the machine also has sensor alarming and counting system .Machine with Automatic double paper feeding system ,ultrasonic /heating
sealing ,oilling,bottom punching,bottom fold,bottom folding，pre-heating ,knurling cup.
Advantages:
1. Multiple feeding for flat fan paper , multiple mediation ,to avoid unevennesss on both sides of fan paper ,to avoid the fan paper jam problem.
2.Machine with 5-6 sensors, to be sure each fan paper run stably in each position ,if any position mistake or failure , machine will start alarm system and stop automatically.
3. Machine with Sheaves and gear together , the part join tightly with each other,no any loosening during machine running ,machine running more accurately.
4. Machine use direct feeding system for paper bottom , use servo motor for feeding bottom paper, use automatic sensor to help the pre-feeding ,avoid waste for bottom paper,reduce the bottom down problem during feeding process.
5.Full machine with automatic time control for oil lubrication ,machine is open cam & reducer motor &automatic-brake system .The automatic-brake system make the machine no any wobble when the machine stopped ,machine more stable. The above advantages make our LXP-80 machine less failure rate, machine more perfect ,provide better service for all customers.
6. The machine has a high-powered blower to blow the bottom paper, bottom waste paper come out from the exit more speedly.
7. Three shafts instaed of 2 shafts during cup body process, make the machine more stable
