The construction site fine stone mortar pump is applied in high-rise building ash mortar and fine stone concrete transportation, secondary structure column grouting, reservoir, hydropower station, port, dock, various pressure grouting, foundation treatment, weak foundation, reinforcement grouting, tunnel Backfill grouting anchor support in subway and mine construction. This product has large displacement, high pressure, labor saving, flexible movement, etc. which is an ideal mortar conveying equipment. The pump is widely used in indoor construction of urban construction projects (such as infusion of structural columns and invisible columns), anchorage grouting, consolidation grouting and backfill grouting works for underground tunnels of urban subway hydropower stations. It can also be used for grouting of anchor piles during slope and soft rock reinforcement.
| Item | Unit | SJBS20-08-37 | |
| Mixing system | Charging | L | 560 |
| Output | L | 350 | |
| Pump system | Maximum flow rate | m³/h | 20 |
| Max.output pressure | MPa | 8 | |
| Mode of distribution | "S"Valve | ||
| Pipe diameter | mm | φ80 | |
| Pipe cleaning | Compressed air or water washing | ||
| Power | kw | 37 | |
| Delivery cylinder*stoke | mm | φ140*800 | |
| Dimension(L*W*H) | mm | 4610*2200*3010 | |
| Weight | kg | 3200 | |
Fangyuan Group have much experience on producing construction machinery, in the past few years, our company product have widely used in the worldwide, for the concrete pump, we have many types, the stationary concrete pump and industrial concrete pump are the hot selling product, and we also have concrete pump with mixer and motar pump, we committed in provide best service with customers.except that, the concrete mixing plant is also popular in the construction yeild, and the tower crane is also trustable in the construction machinery.
Key features:
If you are interested in the product, contact 2bvideo.com for more information for more information
