ZGFM-H series Automatic high speed flute laminating machine
Performance characteristics
1. Cardboard laminates with corrugated or cardboard laminates with cardboard.
2. Automatic detect of top and bottom paper, automatic servo correction technology. Make the top paper automatically track and fit the bottom paper, and the accuracy is high.
3. The bottom paper feeding part use servo motor controlling system, with Japan NITTA suction belt and big air blower to ensure smooth feeding of 2ply, 3ply, 4ply, 5ply and cardboard.
4. Adopt servo motor system realizes automatic adjustment of glue volume and roller pressure. When change order, it will be more fast and convenient.
5. The multifunctional rack of the bottom paper are suitable for curved corrugated.
6. Stainless steel glue roller with fine anilox grinding to guarantee even glue coating even at min glue quantity. 160mm diameter anilox roller can ensure the stability when machine at high speed.
7. Two sets free-cleaning pressure roller (160mm in diameter) are not afraid to dip glue and reduce the workload.
8. Main wallboard updates to 25mm thickness, more run more steady.
9. Use a circulating glue system to reduce glue loss and stabilize glue adhesion effect.
10. One -click adjustment of the whole machine (just enter the paper size).
11. Video monitoring (optional).
Parameters：
|
Model |
ZGFM 1450H |
ZGFM 1650H |
ZGFM 1900H |
ZGFM 2200H |
|
Max size |
1500*1500mm |
1700*1700mm |
1900*1900mm |
2200*2200mm |
|
Min size |
360*380mm |
360*400mm |
500*500mm |
500*500mm |
|
Top Paper |
120-800g |
120-800g |
120-800g |
120-800g |
|
Bottom paper |
≤10mm ABCDEF corrugated board ≥300gsm cardboard |
≤10mm ABCDEF corrugated board ≥300gsm cardboard |
≤10mm ABCDEF corrugated board ≥300gsm cardboard |
≤10mm ABCDEF corrugated board ≥300gsm cardboard |
|
Max speed |
180m/min |
180m/min |
180m/min |
180m/min |
|
Power |
22kw |
25kw |
27KW |
30KW |
|
Stick accuracy |
±1mm |
±1mm |
±1mm |
±1mm |
|
Glue consumption |
15-20g/㎡ |
|||
