1.WORKING PRINCIPLE
Material powder particles, in the raw material container (fluidized bed) in a circular fluidization state, by the purification of the heated air preheating and mixing, the adhesive solution emulsified into the spray, so that a number of particles aggregated into aggregates containing adhesive. Due to the continuous drying of the material by hot air, the water in the aggregates evaporates and the adhesive solidifies. This process is repeated to form the ideal uniform spherical particles with multiple micropores
2.MAIN APPLICATION
Pharmaceutical industry: tablet granule, granule granule, capsule granule
Food industry: cocoa, coffee, milk powder, granular juice, condiments and so on
Other industries: pesticide, chemical fertilizer, feed, pigment, dye chemical industry, powder or granular wet material drying
Coating industry: pellet, outer protective layer, color preparation, slow release, film, enteric coating, etc
3.FEATURES
Through powder granulation, improve fluidity and reduce dust flying
Through powder granulation, its solubility can be improved
Mixing - Granulating - drying - in one machine (one-step granulating)
Using antistatic filter material, safe operation of equipment
Pressure relief hole, once explosion, equipment personnel will not be hurt
The equipment has no dead Angle, easy loading and unloading, clean and meet GMP standards
4.TECHNICAL PARAMETER
|
Type |
FL-B3 |
FL-B5 |
FL-B30 |
FL-B60 |
FL-B120 |
FL-B200 |
FL-B300 |
FL-B500 |
|
Container of raw material diameter(mm) |
300 |
400 |
700 |
1000 |
1200 |
1400 |
1600 |
1800 |
|
Container of raw material volume(L) |
12 |
22 |
100 |
220 |
420 |
670 |
1000 |
1500 |
|
Min capacity(batch/kg) |
1.6 |
4 |
15 |
30 |
80 |
100 |
150 |
250 |
|
Max capacity(batch/kg) |
4 |
6 |
36 |
72 |
140 |
240 |
360 |
600 |
|
Consume of stem(batch/kg) |
12 |
23 |
70 |
140 |
211 |
282 |
366 |
465 |
|
Amount of compressded aie(m3/min) |
0.3 |
0.3 |
0.3 |
0.6 |
0.6 |
0.9 |
1.1 |
1.6 |
|
Power of fan(kw） |
2.2 |
4 |
5.5 |
11 |
18.5 |
22 |
30 |
45 |
|
Temperature(℃） |
normal temperature -120℃ automatic adjustment |
normal temperature -120℃ automatic adjustment |
normal temperature -120℃ automatic adjustment |
normal temperature -120℃ automatic adjustment |
normal temperature -120℃ automatic adjustment |
normal temperature -120℃ automatic adjustment |
normal temperature -120℃ automatic adjustment |
normal temperature -120℃ automatic adjustment |
|
Yield % |
＞99 |
＞99 |
＞99 |
＞99 |
＞99 |
＞99 |
＞99 |
＞99 |
|
Operate time （min） |
15-30 |
15-30 |
15-30 |
15-30 |
15-30 |
15-30 |
15-30 |
15-30 |
|
Content at final term % |
-0.2 |
-0.2 |
-0.2 |
-0.2 |
-0.2 |
-0.2 |
-0.2 |
-0.2 |
|
Noise DB |
≤75 |
≤75 |
≤75 |
≤75 |
≤75 |
≤75 |
≤75 |
≤75 |
|
Height of main machine(mm) |
2100 |
2300 |
2500 |
3000 |
3300 |
3800 |
4000 |
4400 |
Remarks:
1.delivery:30 working days in factory
2.Payment:30% advance,70% before shipping by TT
3.We are manufacturing company with the factory price and high quality
4.We can provide offer with FOB,CIF,CFR as consumer requirmenrts
5.If u feel interested in this machine or sifting machine or spices pulverizer or granulator or powder mixer machine or capsule filling machine or capsule polishing machine or capsule counting machine etc someday that we produced u can tell me your specific requirement so that i can better recommend more suitable for your demands machine,what do u think
