Model |
WPV200 |
|
Bag size |
(L)80-300mm (W) 80-200mm |
|
Film width |
Max.420mm |
|
Film thickness |
0.05-0.10mm |
|
Packing range |
10gs-1000gs/bag |
|
Packing speed |
20-90 bags/min |
|
Air consumption |
0.65Mpa, 0.4m³/min |
|
Power supply |
220V/380V 50-60Hz |
|
Power |
4.5KW |
|
Dimension |
L2860 x W2580 x H3450mm |
|
Weight |
1980kgs |
|
Packing material |
All laminated film such as PET/PE, PET/AL/PE, Nylon/PE, etc.; PE (confirm when order) |
|
We have several models. We can customize the right model for you according to your requirements. Please contact us for more information. |
|
Main Features
1.Equipped with safety protection,comply with firm's safety management requires.
2. PLC and HMI controller, easy to operate and maintain.
3.Servo film pulling system,photocell accuracy cutting position.
7. Have error indicating system, helping handle the trouble immediately.
8. The device of gusseted bag, linked bag, punching device ect for optional.
1. How do I know the packing machine model is suitable for my product?
Weeshine: Please advise all the below details of your product and we will check for you.
1.Product details
Weeshine: All our machines are tailor-made as different customers have different requirements, delivery
will be within 15 working days for the small packing machines. It takes longer time for the large-scale
machine.
Weeshine: Yes, of course. We also could help you to test your product on our packing machine and
record a video for your reference if you could send some samples to us.
4. Are you factory or trading company?
Weeshine: We are the factory, and especially R&D, manufacture and sell various packing machines.
We have engaged in the packing R&D and production over 20+ years.
5. How can we make sure about the machine quality after we make the payment?
Weeshine: We will send you the pictures and videos for you to check the quality, you are welcome
to check the quality by yourself before shipping as well.
