DGR-IIB
Fully Automatic Steel Belt Strapping Machine Head with Anti-loosening and Free Buckle |
|
| Power Source | Daily Maintenaance |
| Voltage: AC380V Belt feeding motor: 3kw Pneumatic parts: Reversing cylinder(pressing-belt-wheel cylinder), half-biting cylinder, full-biting cylinder, anti-loosening cylinder, flanging cylinders Pressure: 4-6bar Instantaneous gas consumption: Max 0.9L/s |
As per general equipment maintenance |
| Strapping Speed | Belt Spec |
| General working time of head in strapping process is 12.8 secs/belt. | Width: 19mm, 25mm,32mm, Thickness: 0.8-1.2mm |
| Steel Belt Connection | Applicable Environment |
| By stamping three pairs of buckles on the steel belt, fold the edges on both sides after the buckles overlap(for increasing the connection force, and prevent the buckle loosening). | Hyperthermal environment and various complex environment. |
| Belt tension | Applicable Objects |
| Max.20000N (adjustable) | Hot rolled coils, hot rolled plates, galvanized coils, cold rolled coils, steel pipe piles, bar piles, plate piles, aluminium ingot piles, steel ingot piles, pipe piles, wood piles, waste piles, etc. |
| Consumable Accessories List | Strength of Steel Belt Joint |
| Feeding-belt wheel, tensioning wheel, belt cutter, biting unit, loose-proof top grain, loose-proof bottom grain, biting unit. | The strength of connecting point accounts for about 65%-75% of the strength of the steel belt itself (influenced by belt's rigidity, toughness, and tensile strength.) |
| Machine Maintenance | |
| Suggest providing minor maintenance every 6 months and major maintenance 1 year. | |
