Product details

Pneumatic Air Waste Paper Box Die Cutting

Pneumatic Cardboard Waste Stripper Carton Box Stripper

1. Die Cutting Waste Stripper is a waste edge removal tool for cardboard, kraft paper, fine corrugated and ordinary corrugated paper in packaging and printing industry.

2. Improve work efficiency and shorten the waste removal cycle. Waste Paper Stripper removal efficiency is close to 10
It is several times higher than the manual removal of garbage.

3. High efficiency, simple operation, it can be executed by pressing the switch.

Factory Price Pneumatic Air Waste Paper Carton Box Die Cutting Stripper

Factory Price Pneumatic Air Waste Paper Box Die Cutting Stripper

Appearance size	450150180mm
Air pressure	0.6-0.8Mpa
Working speed	2500-4500RPM
Weight	3.3-5.5Kg
Five rows of fine teeth	-strong force, suitable for paper edge>7mm products -Suitable for color box, cardboard, tag, fine flute, general purpose and the removal of products with a paper edge larger than 7mm
Double row single claw	-strong force, suitable for wide and thick paper -Suitable for corrugated paper of various specifications, gray board paper (very hard cardboard, such as leather shoe boxes), the waste edge is larger, and the waste edge is more than 15mm (suitable for 2/3/4/5 ply corrugated boxes) .
Double row double claw	-Wide range of applications -Suitable for use in card boxes with more than 150 grams, gray boards or boxes after laminating, single-layer corrugated boxes of various specifications, flute paper, etc., and the waste edge width is more than 10mm.

How to use the pneumatic waste stripper correctly?

-The pneumatic waste removal machine needs to be equipped with an air compressor above 1.5KW and an 8*12 connecting air pipe to ensure the powerful rotation of the rotor.

-First, make sure that the pneumatic waste cleaner is connected to the air source to ensure that the air pressure is 8 kg force to work normally.

-Before the air pressure is turned on, the chain can be driven by hand, and can it roll freely, otherwise it cannot be used.

-Turn on the slide switch before working.

-Inject professional pneumatic tool oil from the air inlet to lubricate the motor.

-Press the pressure plate while working to start working.

-Stack the paper stacks that need to be discarded neatly, all sides are flush, and the tops are pressed with iron plates.There must be knife edges on the four sides.All the waste edges must be ≥ 5mm when leaving the edge.

-Three or four drops of special oil for pneumatic tools should be dripped from the air inlet before each shift, idling for 2-3 seconds.

Pneumatic Stripper corrugated machine spares

Die Cutting Waste Stripper corrugated machine spares

1. Q: Are you a manufacturer, trading company or a third party?
A: We are a manufacturer, located in National High-tech Industrial Zone, Sanshui, Foshan City, Guangdong Province, China. Warmly welcome to visit our company.

2. Q: What is your minimum order quantity, can you send me samples?
A: Our minimum quantity is 1 set.
With over 3500+ sucessful installation experience in the last 22 years, we provide tailor-made solutions as per customer's demand.

3. Q: How does your factory do regarding quality controlling?
1). 22 Years of Specialization in Corrugated Industry Solutions that delight
2). Over 3500+ successful installation corrugated cardboard production line
3). Quick Responsive Professional Pre-sales Service
4). Top machinery R&D team
5). A state-of-the art factory with full set up of manufacturing facilities, including 4 Sets of advanced 5-face High Precision
CNC Center
6). Strict inspection before delivery
7). All-round after-sales Service System
8). Fuli is the unique company who drafts the latest version of national industry standard for corrugated machines in China

4. Q: How about the after-sale service?
All-round after-sales Service System
Engineers team provides solutions in the field of Mechanic/ Electric/ Operation.
TM online for 24 hours.
Online Quick Responsive service: Email, skype, MSN, FB, Linkin, Wts, IG.
One year warranty period under normal use for machines.
