Ball screw 0603 with flange nut, designed and produced by our own brand WKT, widely used in opto and medecial field. 0601 Ball Screw also called 0601 ball bearing screws, 0601 recirculating ball screws, consist of screw spindle and a nut integrated with balls and balls’ return mechanism, return tubes or return caps. Miniature 0601 nut is Floating deflector cycle mode, and the nut shape is round nut with flange. The diameter length is 6 mm, the lead/pitch length is 1 mm.
Features：
(1) Lead Accuracy Up to Grade C3 C5 C7 and C10 ,screws have been Standardized. C5 on request.
(2) Precision Ground Ball Nut High Precision Ball Nut are interchangeable between ground and rolled screws.
(3) Available to ship separately ball screw and ball nuts can be shipped separated ensure shortest delivery time. The ball nuts are standardized with light preload, also the preload value can be adjusted to zero or heavy.
Ball screw 0601 with flange nut, we make full use of features of Miniature Ball screw manufacture and super compact design actuator can achieved the high precision C3 according to our customers’ requirement. The diameter of one of the screw shaft ends must be less than the screw shaft root diameter, otherwise ball nut cannot be installed.
For Application field, Ball screw 0601 with flange nut also used in machine tools, robots and precision assembly equipment. High precision ball screws are used in steppers for semiconductor manufacturing.Ball screws are used in aircraft and missiles to move control surfaces, especially for electric fly by wire, and in automobile power steering to translate rotary motion from an electric motor to axial motion of the steering rack.
SCREWTECH company, since its establishment in 2007, nearly two hundred employees, provide continuous high quality product and fast response service. Quality is the foundation of SCREWTECH. We are committed to serving every customer and providing products that meet strict standards to ensure quality, durability and precision. Customers provide drawings (CAD and 3D drawings are both available), and sales engineer check feasibility, then submit drawings to our professional engineers and make suitable proposal.Miniature ball screw is composed of screw, nut and ball.It has the characteristics of high precision, reversibility and high efficiency. Advantages: long service life, high speed, low heating, no crawling - high precision - high efficiency, less input power, no axial clearance.
Main Features
1.High mechanical efficiency
2 .Axial play
3. High precision
4. Long service life
Accuracy grade: C3, C5, C7
Other characteristics: Smooth running
Name: Ball Screw
Brand: WTK
Original: Suzhou, China (Mainland)
Packaging Details:
In cartons or Wooden cases upon your requirement
For samples:
we have DHL, FEDEX VIP account, so the shipping freight will be much cheaper after discount.
For bulk order:
we have freight forwarder to ship by air,by train or by sea.You can also arrange shipping through your own agent.
Port:
Shanghai
Lead Time:
7-15 days
