CNI provides OEM DPSS and diode lasers for entertainment. Single wavelength in green, blue, yellow, red and multi-wavelength RGB lasers are optional. About RGB mix solution for customers, you can make full color show lasers at any output power up to 50 watts.These lasers are designed with high reliability and ultra compact dimensions, can be perfectly integrated into customers' projectors.
CNI also provide supporting photosynthetic perfect system for customers, including engineering drawings, photosynthesis, laser and other necessary accessories.According to customer demand, to provide high power red, green, blue and other monochromatic laser light combination system.
Spectificatios
|
Green Laser Series - 532nm |
||||||||
| Model | OEM-I-532 | OEM-F-532 | OEM-N-532 | OEM-W-532 | OEM-D-532 | MGL-H-532 | MGL-F-532 | MGL-D-532 |
|
Wavelength (nm) |
532 |
|||||||
|
Outout power (mW) |
1-5000 | 500-3000 | 3W-5W | 6W-8W | 20W-30W | 500-1500 |
1.5W-2.5W |
20W-30W |
|
Power stabilty (rms) at 25℃ |
<1%, <2%, <3%, ,5%, <10% (depending on different model) |
|||||||
|
Transverse mode |
Near TEM00/ TEM00 (TEM00 of MGL-F-532) |
|||||||
|
Beam divergence (mrad) |
~1.0 | <1.2 | <1.0 | <1.5 | <2.0 | <2.0 |
<1.2 |
<2.0 |
|
Beam diameter (mm) |
~3.0 | 3~4 | ~3.0 | ~5.0 | ~5.0 | ~3.0 |
~2.4 |
~5.0 |
|
Warm-up time (minutes) |
<10 | <5 | <10 | <10 | <10 | <10 |
<10 |
<10 |
| TTL/ Analog modulation |
TTL/ Analog with 1Hz-1kHz, 1Hz-10kHz, 10kHz-30kHz optional |
|||||||
|
Green Laser Series - 520nm |
||||||
| Model | OEM-F-520 | OEM-D-520 | OEM-GD-520 | OEM-XD-520 | OEM-KD-520 | OEM-BD-520 |
| Wavelengeh (nm) |
520 |
|||||
| Output power (mW) | 1-800 | 1W-3.5W | 3.5W-5W | 7W-8W | 6W-10W | 11W-20W |
| Power stability (rms) |
<1%, <3%, <5% |
|||||
| Beam divergence (mrad) | <1.3x0.1 | <1.4x0.8 | ~1.2 |
<1.5 |
~1.2 | ~1.2 |
| Beam diameter (mm) | ~1.5x3.5 | ~3.5x5 | ~5.5x6 | ~7.5x5 | ~5.5x6 | ~5.5x6 |
| Warm-up time (minutes) |
<5 |
|||||
| TTL/ Analog modulation |
TTL/ Analog with 1Hz-1kHz, 1Hz-10kHz, 1Hz-30kHz, 1Hz-100kHz optional, TTL on/ off |
|||||
|
Blue Laser Series - 447/ 455/ 462/ 465nm |
|||||||||
| Model | OEM-F-447 | OEM-D-447 | OEM-GD-447 | OEM-XD-447 | OEM-KD-455 | OEM-BD-455 | OEM-GD-462 | OEM-KD-462 | OEM-F-465 |
| Wavekength (nm) |
447 |
|
|
|
455 |
|
462 |
462 |
465 |
| Output power (W) | 1-3.5 | 4-8 | 9-16 | 17-28 | 30-36 | 40-50 | 16 | 20-30 |
1-3 |
| Power stability (rms) |
<1%, <3%, <5% |
||||||||
| Beam divergence (mrad) | 0.7x0.1 | ~1.4x0.2 | <1.4x0.8 | <1.8x0.8 | ~1.2 | ~1.2 | ~1.2 | ~1.2 |
0.7x0.1 |
| Beam diameter (mm) | ~2.7x2.7/ ~3.5x3.5 | ~3.2x0.2/ ~4.2x4 | ~7x5 | ~7.5x7 | ~6.5x7 | ~8.5x7 | ~5x7 | ~4.5x7/ ~6.5x7 |
~3.5x3.5 |
| Warm- up time (minutes) |
<5 |
||||||||
| TTL/ Analog modulation |
TTL/ Analog with 1Hz-1kHz, 1Hz-5kHz, 1Hz-10kHz, 1Hz-100kHz optional, TTL on/off |
||||||||
| Red Laser Series - 635nm | |||||
| Model | OEM-D-635 | OEM-GD-635 | OEM0XD-635 | OEM-BD-635 | OEM-TD-635 |
|
Wavelength (nm) |
635 |
||||
| Output power (W) |
1-2 |
3-6 | 7-11 | 15-20 | 25-30 |
| Powert stability (rms) |
<1%, <3%, <5% |
||||
| Beam divergence (mrad) | ~1.6x0.2 | <1.2 | ~8.5x7.5 | ~8.5x9 | ~8.5x13 |
| Beam diameter (mm) | ~5.0x3.8/ ~5.5x4 | ~6x7.5 | <1.2 | ~1.8 | ~1.8 |
| Warm- up time (minutes) |
<5 |
||||
| TTL/ Analog modulation |
TTL/ Analog with 1Hz-1kHz, 1Hz-5kHz, 1Hz-10kHz, 1Hz-100kHz optional, TTL on/off |
||||
|
Yellow Laser Series - 589nm |
|||
| Model |
MGL-F-589 |
MGL-N-589 | MGL-W-589 |
| Wavelength (nm) |
589 |
||
| Output power (mW) | 1-300 | 300-800 | 800-4500 |
| Power stability (rms) | <10% |
<3%, <5%, <10% |
|
| Beam divergence (mrad) | <2.0 | <1.5 | <2.0 |
| Beam diameter (mm) | ~3.0 | ~3.0 | ~5.5 |
| Warm-up time (minutes) |
<10 |
||
| TTL/ Analog modulation |
TTL/ Analog with 1Hz-1kHz, 1Hz-10kHz, 1Hz-30kHz optional |
||
|
RGB Laser Series (Multi-Wavelengths Laser) |
|||||
| Model | RGB-KD-(635/520/455) | RGB-BD-(635/520/455) | RGB-FD-(635/520/455) | RGB-GD-(635/520/447) |
RGB-XD- (635/520/447) |
| Wavelength (nm) | 635/ 520/ 445 | 635/ 520/ 447 | |||
| Output power (W) | 13 | 20 | 35 | 4/ 6/ 8 | 10-12 |
| Power stability (rms) |
<1%, <3%, <5% |
||||
|
Beam divergence (mrad) |
1.2 | 1.2 | 1.2 | 1.5x0.3/ 1.6x0.4 | 1.9x2.3/ 1.4x0.8/ 1.4x0.2 |
| Beam diameter (mm) | 6x7.5/ 5x5.5 | 6x7.5/ 5x5.5 | 6x7.5/ 5x5.5 | 5x4.5/ 6.2x5.2 | 6x6/ 3.5x5/ 3.2x3.2 |
| Warm- up tome (minutes) |
<5 |
||||
| TTL/ Analog modulation |
TTL/ Analog with 1Hz-5kHz, 1Hz-10kHz, 1Hz-100kHz |
||||
Certifications
Copmpany Information
Changchun New Industries (CNI), founded in 1996, located in Changchun, CHINA, is a manufacturer of solid-state and diode laser systems. CNI possesses accountable and dependable service as well as quality products with compact design, high reliability, excellent performance. The products are widely used for scientific research, equipment manufacturing, biomedical experiment, precision measurement, entertainment, radar communication, material processing, process control, online detection, investigation equipment and other fields.
