Steel H Beam

3 year ago

135 0

Shandong Rizhaoxin Metal Products Co., Ltd.

 3 year year

Product details

S275JR is carbon structural steel and low alloy structural steel for engineering and structure.S275JR Mild Steel H Beam.H-beams are economical section and high-efficiency profile with more optimized cross-sectional area distribution and more reasonable strength-to-weight ratio. It is named because its cross section is the same as the English letter "H". Since all parts of the H-beams are arranged at right angles, the H-beam has the advantages of strong bending resistance, simple construction, cost saving and light weight in all directions, and has been widely used. The section shape is similar to an economical section profile of the capital Latin letter H, also known as universal steel beam, wide edge (edge) I-beam or parallel flange I-beam. The cross-section of H-beam usually includes two parts, the web plate and the flange plate, also known as the waist and the edge. H-beams are widely used and are mainly used for: various civil and industrial building structures; various large-span industrial plants and modern high-rise buildings, especially industrial plants in areas with frequent seismic activity and high temperature working conditions; requiring large bearing capacity and cross-section Large bridges with good stability and large span; heavy equipment; highways; ship skeletons; mine support; foundation treatment and embankment engineering; various machine components.

Steel Pipe Coil Plate Sheet Tube

Product Name	S275JR Mild Steel H Beam
Standard	S275JR
Material	GB:Q225A ASTM:A570 GR.A JIS:SS 400 DIN:RST42-2
Technology	Hot Rolled ,Cold Rolled
Chemical Composition	C:≤0.21% Mn:≤1.5% P:≤0.045% S:≤0.045% N:≤0.009%
Mechanical Property	Yield Strength (MPa)≥:275 Tensile Strength (MPa):430-580 Elongation %≥:23
Tolerance	Control with in the standard, OD:+/-1%, WT:+/-5%
Application	Widely used in automobiles, motorcycles, gas springs, hydraulic machinery, construction machinery and refrigeration industry
Payment Terms	1.FOB 30%T/T,70% Before shipment 2.CIF 30% Pre-payment , Balance must be paid before shipment 3.Irrevocable 100% L/C at sight
Third Party Inspection	SGS ,BV, MTC
Advantages	1.Short delivery time 2.Quality assurance 3.Competitive price, 4.Free Sample
Delivery Time	Within 25 days after receipt of advance payment

H-beams can be produced by welding or rolling. Welded H-beam is to cut strip of suitable thickness to suitable width, and weld the flange and web together on a continuous welding unit. Welded H-beam has the disadvantages of large metal consumption, difficult to ensure uniform product performance, and limited size specifications. Therefore, H-beams are mainly produced by rolling method. In modern steel rolling production, H-beams are rolled using universal rolling mills. The web of the H-beam is rolled between the upper and lower horizontal rolls, and the flanges are rolled and formed simultaneously between the side of the horizontal roll and the vertical roll.

Applications of Hot sell structural galvanized steel h beam with low price
Widely use in construction and other posting application. Size from 100*100mm to 900*300mm , weight per meter from 17.2Kg to 286Kg. The standard length is 6 meters and 12 meters. The most popular grades are Q235B (Equivalent with St37.2, S235JR,ASTM A36) and Q345B (Equivalent with St52.3, S355JR).
Hot sell structural galvanized steel h beam low price Applications: Use in construction and other posting application or steel structure. Hot sell structural galvanized steel h beam low price Advantage:
We have very good business channels with local mills. We always supply the quality steel products in very competitive price and make every process including produce, domestic transportation, inspection and shipment under our control.

Packaging	Standard seaworthy export packing, other types of packing can be customized as every requirement.
Shipping packaging	Bundled with firm steel straps, easy for loading and unloading.

Q: Are you a manufacturer?
A: Yes , we are a seamless steel pipe manufacturer, We have own factory, which is located in Shandong,China. We have a leading power in producing and exporting various steel products. We promise that we are what you are looking for.
Q:Can we visit your factory ?
A:Warmly welcome once we have your schedule we will pick you up .
Q: Do you have quality control?
A: Yes, we can accept BV, SGS third inspection .
Q: Can you arrange the shipment?
A: Sure, we have permanent freight forwarder who can gain the best price from most ship company and offer professional service.
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 25-35 days if the goods are not in stock, it is according to quantity.
Q:How can we get the offer?
A:Please offer the specification of the product,such as material,size,shape,etc.So we can give the best offer.
Q:Can we get the some samples?Any charges?
A:Yes,you can get available samples in our stock.Free for real samples,but customers need to pay the freight cost.
Q: How do you make our business long-term and good relationship ?
A: 1.We keep good quality and competitive price to ensure our customers' benefit.
2.We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
