Ud200 Big Heavy Linear Actuator for Solar Tracker System
U200B is a very compact actuator designed for industrial, medical application. It is very small, and its min. installation space is 108mm+ stroke.
Voltage
12/24 VDC
Max. Load
2,000N
No- Load Speed
5 ~ 37mm/s
Full-Load Speed
4 ~ 22mm/s
Duty Cycle
10%
Protection Class
IP65
Noise Level
≤50dB
Ambient Temperature
-35℃ ~ +50℃
| Parameters | |||||
| CODE | RATED LOAD(N) | RATED CURRENT(A) | RATED SPEED(MM/S) | ||
| PUSH | PULL | NO LOAD (32VDC) | PULL LOAD(24VDC) | ||
| STAND MOTOR (2700RPM) | |||||
| A | 2000 | 2000 | 2.2 | 8.0 | 5.0 |
| B | 1000 | 1000 | 2.5 | 12 | 7.0 |
| C | 500 | 500 | 2.5 | 27.0 | 16.0 |
| FAST MOTOR(3800RPM) | |||||
| A | 2000 | 2000 | 2.8 | 12.0 | 7 |
| B | 1000 | 1500 | 2.8 | 17.0 | 10 |
| C | 500 | 500 | 2.8 | 37.0 | 22.0 |
UPLIFT leads the way in creating great experiences by offering a range of height adjustable desk, linear actuator and sheet metal products and services designed to help people reach their full potential.Our main products are Electric Standing Desk,Pneumatic Standing Desk,Hand Crank Standing Desk,Desk Lifting Columns,Desk Controller,Desk Control Boxes,Desk Accessories,Home Electric Linear Actuator,Industrial Electric Linear Actuator,Standing Desk Frame,Height Adjustable Desk,Adjustable Height Desk,Electric Adjustable Height Desk,File Cabinet and so on.
Our comprehensive portfolio anchored by UPLIFTEC brand, which registered a trademark with 5 patent applications in China. Together with our partners, we design spaces to help people work, learn and heal.
We drive sustainable social, economic and environmental change through our decisions and actions. At UPLIFT,we don't just do what's right, we do what's best - for people and for the planet.
