T335（3ZW130）Triplex Plunger Pump

The YouLong Model T335 is a single acting triplex plunger pump rated at 335 HP in intermittent duty services . This versatile pump is offered with a variety of material and design options that make it ideal for general industrial, high pressure cleaning, and typical applications involved in the production of oil and natural gas.

Specifications
	English Units	Metric Units		Continuous	Intermittent
Stroke Length		130 mm	Rated bhp		335 HP
Rated Rod Load	23810 lb	10800 Kg	Maximum Speed
Pump Weight	1984 lb	1100 Kg	Minimum Speed		90 rpm
Gear Reduction Ratio	3.5:1/ 4.086:1/ 4.619:1		Max. plunger size x stroke length.	75x130mm
Max. Fluid Temp	°F	90 °C	Pinion shaft extension:	65x100 mm
Mechanical Efficiency		85%	Keyway (width x depth x length)	16x6x90 mm

Performance Ratings（Volumes indicated are displacement of incompressible fluid）

Input Speed ：1480rpm					Gear Ratio： 3.5:1	Input Speed ：1776rpm					Input Speed ：1480					Gear Ratio ： 4.086：1	Input Speed ：1776rpm					Input Speed ：1480rpm					Gear Ratio ： 4.619：1	Input Speed ：1776rpm
Pump Speed ：422rpm					Gear Ratio： 3.5:1	Pump Speed： 507rpm					Pump Speed ：362rpm					Gear Ratio ： 4.086：1	Pump Speed ：434rpm					Pump Speed ：320rpm					Gear Ratio ： 4.619：1	Pump Speed ：384rpm
Power		200	220	250	Plunger Dia. mm	200	220	250	Power		Power		200	220	250	Plunger Dia.mm	200	220	250	Power		Power		200	220	250	Plunger Dia.mm	200	220	250	Power
Rated Flow		Rated Pressure (Mpa)				Rated Pressure (Mpa)			Rated Flow		Rated Flow		Rated Pressure (Mpa)				Rated Pressure (Mpa)			Rated Flow		Rated Flow		Rated Pressure (Mpa)				Rated Pressure (Mpa)			Rated Flow
L/min	m³/h	Rated Pressure (Mpa)				Rated Pressure (Mpa)			L/min	m³/h	L/min	m³/h	Rated Pressure (Mpa)				Rated Pressure (Mpa)			L/min	m³/h	L/min	m³/h	Rated Pressure (Mpa)				Rated Pressure (Mpa)			L/min	m³/h
41	2.46	250	265	280	18	200	225	255	50	3	35	2.1	280			18	220	250	280	43	2.58	31	1.86				18	250	280		38	2.28
51	3.06	200	225	255	20	160	175	210	62	3.72	44	2.64	220	250	280	20	180	200	240	53	3.18	39	2.34	250	280		20	210	230	270	47	2.82
62	3.72	160	175	210	22	135	150	175	75	4.5	53	3.18	180	200	240	22	160	170	200	64	3.84	47	2.82	210	230	270	22	175	195	230	56	3.36
74	4.44	135	150	175	24	115	125	150	89	5.34	63	3.78	160	170	200	24	135	150	175	76	4.56	56	3.36	175	195	230	24	150	165	195	67	4.02
87	5.22	115	125	150	26	100	110	125	104	6.24	74	4.44	135	150	175	26	115	125	150	89	5.34	66	3.96	150	165	195	26	125	140	165	79	4.74
100	6	100	110	130	28	85	95	110	120	7.2	86	5.16	115	125	150	28	100	110	125	104	6.24	76	4.56	135	150	175	28	110	125	145	92	5.52
116	6.96	85	95	110	30	70	80	95	139	8.34	99	5.94	100	110	135	30	85	95	110	119	7.14	88	5.28	115	125	150	30	95	105	125	105	6.3

*Flows are based on 100% volumetric efficiency. Brake Horsepower /Kilowatts Required is based on 90% Mechanical Efficiency.Consult YouLong for continuous service speeds in excess of 380 RPM. Not all plunger sizes are shown, additional plunger sizes are available.

Please contact YouLong for more details. Standard configuration is a singleextended crank, double extending crankshaft please contact YouLong. Discharge and Suction Connection mode and size please contact YouLong.The information and data on this sheet is accurate to the best of our knowledge and belief, but are intended for general information only. Applications suggested for the materials are described only to help readers make their ownevaluations and decisions, and are neither guaranteesnor to be construed as express or implied warranties of suitability for these or other applications. YouLong makes no warranty either express or implied beyond that stipulated in YouLong Standard Terms and Conditions of Sale.
