Rotary Screener
SFJH series rotary flat sieve adopted a special balance system to ensure the full balance of inertia force in different direction when running; at the tail it adopted elastic support to reduce vibration and noise; At front end, middle and after end of the machine there respectively proceeding circular motion, elliptic motion, and reciprocating rectilinear motion,plus equipped with sieve cleaning device, therefore the capacity and efficiency is high, whereas the power consumption is low. This machine is used to grade granular materials and crumbled feed and to proceed secondary circulation crush, and to clean and grade some granular and powder materials.
The vibrating screen is designed with the barrel type of eccentric shaft vibration exciter and eccentric block to adjust the swing.
Designed with a simple structure, with eccentric block as excitation, strong vibrating force, low electricity consumption and low noise.
Uses small amplitude, high frequency and big angle structure which enables it to have high screening efficiency and great handling capacity.
Uses large clearance bearings and is lubricated with thin oil. It causes little noise and has a long service life.
|
Type |
Power(kw) |
Material |
Capacity(t/h) |
Screen surface(mm) |
Size(mm) |
||
|
A |
B |
C |
|||||
|
SFJH80×2C |
1.5 |
Pellet |
5-8 |
1600*800 |
2640 |
1310 |
1136 |
|
Mash |
4-6 |
||||||
|
SFJH100×2C |
3 |
Pellet |
8-10 |
2140*1000 |
3270 |
1510 |
1363 |
|
Mash |
6-8 |
||||||
|
SFJH120×2C |
4 |
Pellet |
10-15 |
2500*1200 |
4320 |
1910 |
1440 |
|
Mash |
8-12 |
||||||
|
SFJH140×2C |
4 |
Pellet |
14-18 |
|
4320 |
1910 |
1435 |
|
Mash |
12-16 |
||||||
Note:Please select 2C or 3C according to customer requirement.
