High Pressure Hydraulic Cable Crimping Compressor
This hydraulic crimping tool is able to crimp the conductor, earth wire, as well as the terminals joining aluminum wires to copper wires. Our product can be divided into various types. Both 16101 and 16102 types are equipped with the manual or single-tube electric pump. 16103, 16104 and 16105 types are fitted with the super high pressure hydraulic pump station. In addition, the matched dies need to be purchased additionally.
Detailed Data
Item number
Model
Maximum Compression(kN)
Maximum oil pressure (MPa)
Suitable copper terminals
Stroke(mm)
Weight (kg)
16101
SCHX-25
250
70
50-630
5.5
16101A
FYQ-630A
316
70
150-630
35
15.4
16101B
SCHX-45
450
70
50-800
10.6
16102
QY-35
350
70
25
12
16103
QY-65
650
94
≤ACSR500
25
25
16104
QY-125
1250
94
≤ACSR720
25
40
16105
QY-200
2000
94
≤ACSR1440
25
85
If you are interested in the product, contact 2bvideo.com for more information for more information
