Product details

Hydraulic Crimping Tool With 9 Pairs of Dies

【Wide Application】 The crimper tool is great for battery and welding cables , power Wires , and electrical cables ,even can be rotated 180° freely for narrow space working
【Comfortable grip】 The vinyl-dipped grip is very comfortable and easy to use and Wont slip
【Easy operation】The mold can be easily replaced by one-way fixed latch

Detailed Data

Item number	16199	16200
Model	CYO-410	CYO-510B
Maximum compression (kN)	120	130
Stroke (mm)	30	38
Range of compression joint	Copper terminals: 50-400mm2	Copper terminals: 50-400mm2
Range of compression joint	Aluminium terminals: 35-300mm2	Aluminium terminals: 35-300mm2
Weight (kg)	6.4	7.4
Dies	Hexagon dies: 50,70,95,120,150,185,240,300,400	Hexagon dies : 50, 70, 95, 120, 150, 185, 240, 300, 400

To support the Transmission work, Marshine Power has Tubular Gin Pole, Come Along clamp, wire rope pulley block, nylon sheave hoisting tackle, hydraulic cable puller and tensioner ,conductor installation devices all are OEM and professionally produced per ISO 9001:2008, which are being sold to over more than 50 countries in the world. Some items like emergency restoration tower and crossing structure, we can customized, and the safety tools and accessories, are not demanded the MOQ. You can freely help you out either Tech issue or Products requirements. Pls approach us. Thanks.
