Bright Annealed ASTM B622 seamless Nickel Alloy Tube Alloy C-4/UNS N06455
ASTM B622 for stainless steel tubes and nickel alloy tubes,nickel alloy pipes.
Materials:nickel alloy pipes UNS N06600/alloy 600,N06601/Alloy 601,N07718/Alloy 718,N04400/Alloy 400,
nickel alloy tubes:N05500/Alloy K500,N06625/Alloy 625,N06455/Alloy C-4
Application:Chemical processing involving wet chlorine, hypochloric acid, hydrochloric acid,
acetic acid and acetic anhydride; flue gas scrubber systems; pickling operations; and electro-galvanizing.
Products: seamless UNS N06455/Alloy C-4 nickel alloy stainless steel tube
Process method: cold drawn seamless stainless tubes or cold rolled seamless stainless pipes
Surface finish: bright annealing, pickling and polishing as required
Specifications: ASTM B163,ASTM B167,ASTM B444,ASTM B622 for nickel alloy steel tubes
Nickel alloy tubing product Size:
A) NPS: 1/8" to 6"
B) Schedule: 10S, 40/40S, 80/80S, 120, 160, XS, XXS
C) Alloy tubes O. D.: 6 mm to 168 mm
D) Alloy tubing W. T.: 0.5 mm to 20 mm
E) stainless tubing length: Max. 25 meters
Packaging: seaworthy wooden case/steel framed plywood case/bundles packaging
Certificate: ISO 9001:2008, PED ASME,Materials certificate as EN10204.3.1B
Advantages:
UNS N06455 has outstanding high-temperature stability, and has excellent resistance to stress-corrosion cracking and oxidizing
atmospheres up to 1040℃. It has exceptional resistance to a wide variety of chemical process environments, including hot
contaminated mineral acids, solvents, chlorine and chlorine contaminated media (organic and inorganic), formic and acetic
acids, acetic anhydride, and seawater and brine solutions.
Nickel alloy steel tubing UNS 06455 Chemical composition:
|
% |
Ni |
Cr |
Mo |
Fe |
Co |
C |
Mn |
Si |
P |
S |
Ti |
|
min |
balance |
14.0 |
14.0 |
|
|
|
|
|
|
|
|
|
max |
18.0 |
17.0 |
3.0 |
2.0 |
0.015 |
1.00 |
0.08 |
0.040 |
0.030 |
0.70 |
Alloy C-4 steel tubes Features:
Alloy C-4 has outstanding high-temperature stability, and has excellent resistance to stress-corrosion cracking and oxidizing atmospheres up
to 1040℃. It has exceptional resistance to a wide variety of chemical process environments, including hot contaminated mineral acids, solvents,
chlorine and chlorine contaminated media (organic and inorganic), formic and acetic acids, acetic anhydride, and seawater and brine solutions.
Related standard:
ASTM B163 ASME SB163) Seamless nickel and nickel alloy condenser and heat exchanger tube
ASTM B165(ASME SB165) Seamless nickel - copper alloy seamless nominal pipe and tube
ASTM B167(ASME SB167) Seamless ni - cr - iron alloy and nickel - cobalt - chromium - molybdenum alloy seamless nominal pipe and tube
ASTM B407(ASME SB407) Seamless nickel - iron - chromium alloy nominal pipe and tube ASTM
ASTM B423(ASME SB423) Seamless nickel - iron - chromium - molybdenum - copper (UNS N08825 and UNS N08221) nominal pipe and tube ASTM
B444 (ASME SB444)（Seamless nickel - chromium - molybdenum, niobium alloy (UNS N06625) and nickel - chromium - molybdenum - silicon alloy
UNS N06219）Nominal pipe and tube
ASTM B622 (ASME SB622) Seamless nickel and nickel - cobalt alloy nominal pipe and tube
ASTM B668 (ASME SB668) UNS N08028 seamless tube
ASTM B690(ASME SB690) Seamless iron - nickel - chromium - molybdenum (UNS N08366, UNS N08367) nominal pipe and tube
ASTM B729 (ASME SB729) Seamless UNS N08020, UNS N08026, UNS N08024 nickel alloy nominal pipe and tube
Tags:N06600 nickel alloy tubes,N06600 nickel alloy pipes,Alloy 600 inconel tubing,UNS N06455 nickel alloy tube
ASTM B622 C-4 nickel alloy tube,N06455 nickel alloy pipe,stainless steel tubing,stainless steel tubes,stainless steel
pipes,
