Grit Classifier / Sand Water Seperator
Products Description
Grit Classifier is also known as a grit screw, grit separator which are used at wastewater plants at the headworks (front end of the plant) to help separate the grit from organics and water. Grit removal needs to be done at the headworks of plants to help reduce wear to upstream pumps and mechanical equipment. Grit can also cause pipe blockage and reduce the effective volume of the treatment basins. Grit classifiers usually consist of a hopper positioned on top of an inclined screw conveyor. Typically grit classifiers are made of stainless steel housing and have a high strength abrasion resistant fights on the screw because of the abrasive application.
Product Paramenters
Model
HLSF-260
HLSF-320
HLSF-360
HLSF-420
Diameter of Screw(mm)
220
280
320
380
Capacity(L/S)
5-12
12-20
20-27
27-35
Motor Power (KW)
0.37
0.37
0.75
0.75
RPM(r/min)
5
5
4.8
4.8
Features
1. It separates and transports sands spirally. It is light because of no underwater bearing which makes its maintenance more convenient.
2. The adoption of new decelerator makes the structure very compact, the operation smooth and the installation more convenient.
3. The using of the flexible bars in U groove, which are wear-resisting, makes the separator work with lower noise, and replace of these bars easily.
4. The whole set enjoys simple installation and easy operation.
5. The sand classifier can be used in many fields, from waste water treatment plants, chemical industry, paper plants, recycling plants to agri-foods, etc. This is the result of advantages such as high performance-cost ratio, easy operation, easy installation and low maintenance needs.
