Natural Antioxidant High Efficiency Fluidized Dryer

Fluidized Drying Machinery use to dry the granules from Granulating machine , such as Instant Particle Granulator, Swaying Granulation Machine , High Speed Granulator, Supper Granulating Machine, Mixing Granulating Machine, High Speed Wet Mixing Granulator.

Natural Antioxidant High Efficiency Fluidized Dryer Principle

When air is purified and heated, it is introduced from the bottom of induced-draft fan and passed through the screen plate of raw material. In working chamber, the state of fluidization is formed through stirring and negative effect. The moisture is evaporated and removed rapidly and the raw material is dried quickly.

Product Features:

1. The structure of fluid bed is round so as to avoid the dead angle

2. The main machine is designed 20% higher than common design, the fluidizing space is expanded to guarantee the flow height of material so that the load of bag deduster be effectively decreased.

Natural Antioxidant High Efficiency Fluidized Dryer Application

1. Use screw to extrude and vibrate granule and granulate the granule with the method of humidity, high speed and mixing

2. Suitable for drying humidity block or powder raw material in the fields such as pharmaceutical, foodstuff, feed stuff, chemical industries and so on
3. The raw material that large in granule and small in block and having adhesive property
4. Suitable for raw materials, its volume will be changed when dry, such as giantarum, polyacrylamide, etc.

Model	GFG-200	GFG-300	GFG-400	GFG-500	GFG-650
Bin capacity(L)	200	300	400	500	650
Production capacity(Kg/time)	30-60	50-100	60-120	70-150	100-200
inlet air temp(ºC)	50-100	50-100	50-100	50-100	50-100
Blower power(kw)	11	15	18.5	22	30
Steirring power(kw)	1.1	1.5	1.5	1.5	1.5
Steam consumption(kg/h)	1440	170	210	240	280
Compressed-air consumption(m3/h)	0.6	0.6	0.6	0.9	0.9
overall dimensions(mm)	2800x1350x2700	2900x1450x2700	3100x1650x2900	3100x1650x3000	3200x1750x3100

Quality control

In order to ensure quality of product, we focus on user 's requirements and control improvement and enhancement quality of products .The quality assurance mainly focus on the processes of ensuring production readiness inspection, control of raw materials and components, process control, critical parts, important parts of quality control, assembly quality control, process control testing, measurement equipment control. Pay close attention to the implementation of the quality assurance work, strictly to three inspection system of self-checking, mutual inspection, special inspection. The key point of Quality assurance is focuses on critical parts, important parts of quality control, the quality standards required by ISO9000 quality control procurement documents in order to clarify its status and acceptance of quality standards for company's re-inspections ; For critical parts and important that the key processes of identification and corresponding technical documentation, control by "the implementation of key quality control process", and complete, accurate and complete original records. Difficulties in quality assurance is a special process control, quality assurance is mainly painting, has developed a special process (painting) process documents, take the appropriate technical measures, to quality assurance.

In the production process, we pay close attention to quality control of each process. Every component, every process was strictly controlled. Enhanced the quality inspection process, the establishment of the necessary quality control point, the process by a full-time staff and quality inspector for inspection and supervision. Improved testing procedures and operating instruction.

OUR SERVICES
Pre-sale service
We invite customers to visit our company and communicate on technical requirements face to face. we also can do test in our lab for free. and then we will use the testing parameter to design final machine to reach client requirement.
Sale service
Responsible for debugging the equipment according to customers' requirements of various technical data. Our engineers will train our customers about equipment features and operation key points to make sure the equipment running in the best condition.

After-sale service
We provide installation, debugging, maintenance, training and other services (Optional); Provide relevant technical data, equipment, software and related GMP certification materials.

Quality promise
Our company promises strictly operate the ISO9001 quality system certification standards and pharmaceutical equipment GMP audit requirements,promise we provide new equipment. Advanced technology,good quality. Equipment operation safe reliable, affordable, easy to maintain.

Equipment warranty period is one year, all the parts for the equipment choose well-known brand.During the warranty when equipment have problem in quality like equipment failure and damage, our company offer free maintenance or replacement.
