Fluid Bed High Efficiency Dryer
1. Desiccated Coconut Dryers made by AISISUS304 , AISISUS316, ,carbon steel and so on .
2. Desiccated Coconut Dryers reach GMP
3. Fluid Bed High Efficiency Dryer is Food Powder Drying Plant
4.Dryer machine can be used with the granulating machine such as Stirring Granulating Machine,Extruding Granulator,Extruding Granulator Machine,Revolving Extruding Granulator,Swaying Granulating Machine,high speed granulator,Swaying Granulator, Wet Powder Granulator, YK Granulating Machine, Continuous Wet Powder Granulator, Instant Particle Granulator, High Speed Granulator, Wet Powder Extruding Granulator, Sieve Granulating Machine.
Fluid Bed High Efficiency Dryer Principle
When air is purified and heated, it is introduced from the bottom of induced-draft fan and passed through the screen plate of raw material. In working chamber, the state of fluidization is formed through stirring and negative effect. The moisture is evaporated and removed rapidly and the raw material is dried quickly.
Product Features
1. The structure of fluid bed is round so as to avoid the dead angle
2. The main machine is designed 20% higher than common design, the fluidizing space is expanded to guarantee the flow height of material so that the load of bag deduster be effectively decreased.
Fluid Bed High Efficiency Dryer Application
1. Use screw to extrude and vibrate granule and granulate the granule with the method of humidity, high speed and mixing
2. Suitable for drying humidity block or powder raw material in the fields such as pharmaceutical, foodstuff, feed stuff, chemical industries and so on
3. The raw material that large in granule and small in block and having adhesive property
4. Suitable for raw materials, its volume will be changed when dry, such as giantarum, polyacrylamide, etc.
Fluid Bed High Efficiency Dryer Parameter:
| Model | GFG-200 | GFG-300 | GFG-400 | GFG-500 | GFG-650 |
| Bin capacity(L) | 200 | 300 | 400 | 500 | 650 |
| Production capacity(Kg/time) | 30-60 | 50-100 | 60-120 | 70-150 | 100-200 |
| inlet air temp(ºC) | 50-100 | 50-100 | 50-100 | 50-100 | 50-100 |
| Blower power(kw) | 11 | 15 | 18.5 | 22 | 30 |
| Steirring power(kw) | 1.1 | 1.5 | 1.5 | 1.5 | 1.5 |
| Steam consumption(kg/h) | 1440 | 170 | 210 | 240 | 280 |
| Compressed-air consumption(m3/h) | 0.6 | 0.6 | 0.6 | 0.9 | 0.9 |
| overall dimensions(mm) | 2800x1350x2700 | 2900x1450x2700 | 3100x1650x2900 | 3100x1650x3000 | 3200x1750x3100 |
