Product details

SeJow High-flexible Industrial Industrial Cable Camera Power Trigger Cable Assembly

SeJow can provide OEM/ODM wiring harness based on your requirements. Wiring harness, also known as cable harness, wire harness, cable assembly, wiring assembly, is an assembly of electrical cables or wires which transmit signals or electrical power.

Industrial wiring harnesses have a wide range of applications,including the internal connection of home appliances, test instruments, equipment, computers and network equipment,as well as the connection of industrial UPS, PLC, CP, inverter,power,monitoring,air conditioning,wind energy and other cabinets.

It needs to withstand high quality requirements of rapid acceleration and deceleration,tension,compression and torsional stresses,and millions of cycles of bending, while being small batch and multi-specification harnesses.

Bas.Info.

Number of pins/holes: 6Pin

Connector type: hr10a-7p-6s

Wire outer sheath: High-flexible PVC

Rated current: 1A

Wire gauge (cross-sectional area): 26AWG (0.14mm square)

Rated voltage: 30V

Copper core material: high-precision oxygen-free copper

Core wire insulation: HDPE

Shielding structure: 360° surround shielding

Elbow/straight head: straight head

Outer sheath color: black

Applicable temperature: -20℃~+80℃

PIN pin/terminal plating: gold plating

Connector rubber core: PC

Contact resistance: ≤10mΩ

Insulation resistance: ≥100MΩ

Plug-in life: 100 times

Environmental protection requirements: ROHS&REACH

Drag chain bending times: 5 million times

Characteristic impedance: 100±15 (TIA568B association standard)

Bandwidth level: Cat 5e (1000Mbps/100Mhz)

Minimum bending radius: 7.5*OD (cable outer diameter)
