| HPM-500卧式不锈钢打包机技术参数/Technical parameters of HPM-500 horizontal stainless steel packing machine | |||||||
| 序号 No. | 参 数 内 容 Number Parameter Content | 备注 Remarks | |||||
| 1 | 侧压油缸 Side pressure oil cylinder |
型 号 model | YG340/280-4300 | 2 pieces | |||
| 公称推力 Nominal thrust | 2500KNx2 | 行 程stroke | 4300MM | ||||
| 2 | 门盖油缸 Door cover oil cylinder |
型 号 model | YG220/160-2040 | 1 piece | |||
| 公称推力 Nominal thrust | 1000KN | 行 程stroke | 2040MM | ||||
| 3 | 开门油缸 Door opening oil cylinder |
型 号 model | YG125/63-150 | 1 piece | |||
| 公称推力 Nominal thrust | 350KN | 行 程stroke | 1100MM | ||||
| 4 | 拔销油缸 Pulling pin oil cylinder | 型 号 model | YG125/63-200 | 2 pieces | |||
| 公称推力 Nominal thrust | 180KN*2 | 行 程stroke | 200MM | ||||
| 5 | 料箱尺寸（长×宽×高）（mm） Bin size (length x width x height) (mm) | 4100*1500*1000 | |||||
| 投料口尺寸（长×宽）（mm） Size of feeding port (length x width) (mm) | 2700*1500*1000 | ||||||
| 6 | 包块尺寸（长×宽×高）（MM）Package size (length x width x height) (MM) | 1500*800*1000 | Customizable | ||||
| 7 | 工作压力 System working pressure（Mpa） | 21.5 (翻包系统 Bag flipping system 6Mpa) | |||||
| 10 | 电动机一 Electric motor one | 型 号 model | Y250M-4 | 功 率power | 37KW | ||
| 转 速 rotating speed | 1450r/min | 数 量 quantity | 2 pieces | ||||
| 11 | 电动机二 Electric motor two | 型 号 model | Y250M-6 | 功 率power | 37KW | 双出轴 Double output shaft | |
| 转 速 rotating speed | 970r/min | 数 量 quantity | 1 piece | ||||
| 12 | 油泵 oil pump | 型 号 model | A7V160 | 压 力 pressure | 31.5Mpa | ||
| 流 量 flow rate | 160ml/r | 数 量 quantity | 3 pieces | ||||
| 13 | 油泵 oil pump | 型 号 model | F40YCY14-1B | 压 力 pressure | 31.5Mpa | ||
| 流 量 flow rate | 40ml/r | 数 量 quantity | 1 piece | ||||
| 由于设备不断更新，参数会有所变动.Due to continuous device updates, parameters may change. | |||||||
