New Design Powder Mixing Machine
Application and Features:
1.The Powder Mixing Machinery are suitable for mixing powder and granulate materials in pharmaceutical, chemical, food stuff, light industry, electronic, machinery, mining, metallurgical and national defense industrial, featuring high evenness mixing.
2. Mixing barrel moves in multiple directions, there is no centrifugal force on the material, as well as no phenomena of gravity segregation, delaminating and accumulation of materials so that the mixing rate can be up to 99.9 percent for the materials with big difference in terms of specific gravity. Therefore, this salt mixing machine is an ideal product current compare with other various mixers.
3. High loading rare (max. loading 80 percent)
4. Control system of Food Powder Mixing Machinery has more choices, such as push button ,HMI+PLC and so on.
5. The feeding system for this New Design Powder Mixing Machine can be by manual or pneumatic conveyor or vacuum feeder or screw feeder and so on
6. Machine materials : AISISUS304 , AISISUS316L, and other material .
7. For the electrical component , we mainly use international brand such as ABB ,Siemens or Schneider.
8. For the cleaning, Erbang can high pressure spray water device to clean the mixing inside.
Product Characteristic:
1. Food Powder Mixing Machine possesses high mixing uniformity.
2. Powder Mixing Machinery is powder and granules mixing equipment,
3. The process of manufacturing Three Dimensional Mixer has achieved GMP.
4. Our Three Dimensional Mixing Machine has been approved CE.
Main Technical Parameter:
| Model | barrel capacity(L) | max loading capacity(L) | max loading weight(Kg) | speed of driving shaft(r/min) | motor power(kw) | overall dimensions(mm) | total weight |
| SYH-1 | 1 | 0.8 | 0.4 | 15-30 | 0.12 | 500x600x600 | 50 |
| SYH-5 | 5 | 4 | 2 | 15-30 | 0.25 | 600x1000x1000 | 150 |
| SYH-15 | 15 | 12 | 6 | 8-15 | 0.37 | 700x1000x700 | 200 |
| SYH-50 | 50 | 40 | 20 | 8-15 | 1.1 | 1000x1400x1200 | 300 |
| SYH-100 | 100 | 80 | 40 | 8-15 | 1.5 | 1200x1700x1500 | 500 |
| SYH-200 | 200 | 160 | 80 | 8-15 | 2.2 | 1400x1800x1600 | 800 |
| SYH-400 | 400 | 320 | 160 | 8-15 | 4 | 1800x2100x1950 | 1200 |
| SYH-600 | 600 | 480 | 240 | 8-15 | 5.5 | 1900x2100x2250 | 1500 |
| SYH-800 | 800 | 640 | 320 | 8-15 | 7.5 | 2600X2380X2500 | 2000 |
