Raisin Mesh Belt Drying Machine

Characteristics:

1. Raisin Mesh Belt Dryer have big capacity

2. Raisin Belt Type Dryer have high efficiency .

3. Raisin Drying Machine have low energy consumption

4. Raisin Special Dryer heated by steam source

Product structures
1. Inlet air system
The inlet air system consists of Primary filter, middle efficiency filter, high efficiency filter (Optional) and heater with accurate temperature control. The inlet air flow, speed and pressure is variable and controllable. For the heater , it can be steam radiator ,electrical heater , gas furnace and so on .
2. Main Machine Structure
mesh-belt generally adopts 12-60 mesh stainless steel mesh and it is drawn by a transmission device The main body structure consists of mesh-belt, belt transmission device , heater, exhaust fan.
3. Exhaust sir system
The exhaust dust collection filter is optionally designed for protect environment.

1. Fruit Drying Machine Descriptions

Fruit Slice Drying Machine is a continuous penetrating flow drying equipment applied for drying pieces strip and particles state materials with good ventilation.

The machine owns the advantages, of fast drying speed, high evaporation capacity and good product quality.

2. Fruit Drying Machine Principles

The materials are uniformly distributed on the mesh-belt by the material feeder. The mesh-belt generally adopts 12-60 mesh stainless steel mesh and it is drawn by a transmission device and move inside the dryer. The dryer is composed of several sections. For each section, the hot air is circulated separately. Part of exhausted gas is exhausted by a special moisture elimination blower. Thewaste gas is controlled by an adjustment valve. The hot air passes through the mesh-belt covered with bring water material away. The mesh-belt moves slowly, running speed can be freely adjusted according to the material collector continuously.

The top and low circulation units can be freely equipped according to the users requirements. The number of section might be selected according to the production demands.

3. Fruit Drying Machine Applications

Fruit Slice Drying Machine is suitable for the materials, such as de-watering de-watering vegetable, herbal medicine of traditional Chinese medicine and others, for which the water content rate is high and the high temperature is not allowed. The machine owns the advantages, that its drying speed is fast, the evaporation strength is high and the product quality is good. The de-watering filtering cake state paste material, after the particle makeing or bar making, can be dried also.

4. Fruit Drying Machine Attentions to Order

(1). Name of liquid materials, nature, solid content (or moisture content), viscosity, surface tension.
(2). Volumetric weight after drying, allowable residue moisture, granularity, allowed high temperature.
(3). Production, total shift hours per day.
(4). Available energy resource and volume of steam, power supply capacity, available volume of coal, oil and steam.
(5). Control requirement: If inlet and outlet temperature are needed automatic controlled.
(6). Requirement of powder collection: If bag collector is needed to install, environmental requirement of tail gasherbal the dewater

Company Introduction
From dryer, mixer to granulator, from unit machine to production line, we have them all. Hywell Machinery is a professional manufacturer of industrial drying machine, mixing machine and granulating machine. Our flagship products include the hot air dryer, vibration fluid bed dryer, belt dryer, vacuum dryer, one dimensional mixer, two dimensional mixer, three dimensional mixer, and high speed granulator and so on. These high-performance machines have extensive applications within industries such as food, medicine and chemical.
Sustained development and a strong emphasis on research and technology have bolstered our quality standards. we seek to achieve the highest level of customer satisfaction through professionally developed drying ,mixing and granulating solutions.
Hywell Machinery constant faith is providing perfect products to customer , excellenting service to customer !

DW Series Belt Drier(Singlelayer or Multi layers)1 (16)

Model	DW-1.2-8	DW-1.2-10		DW-1.6-8		DW-1.6-10		DW-2-8		DW-2-10
Unit Qty	4	5		4		5		4		5
Blet Wide (m)	1.2	1.2		1.6		1.6		2		2
Drying Lengthm)	8	10		8		10		8		10
Thickness (mm)	10-80
Inlet Temp (℃)	60-200
Steam Pressure(Mpa)	0.2-0.8
Steam Consumption (kg/h)	120-300		150-375		150-375		170-470		180-500		225-600
Drying Time (h)	0.2-1.2		0.25-1.5		0.2-1.2		0.25-1.5		0.2-1.2		0.25-1.5
Evaporating Water (kgH2O/h)	60-160		80-220		75-220		95-250		100-260		120-300
Fan Power(kw)	8.8		11		12		15		16		20
Total Power(kw)	10.1		12.3		13.3		16.3		17.3		21.3
