Medicine Powder Mixing Machine

Product Application:
Medicine Powder Mixer is widely used as the mixing machine for solid medicine powder in pharmaceutical industry worldwide. The mixing uniformity of Medicine Powder Blender is high, the material vessel is movable, these are very convenient for material loading, mixing, discharging and cleaning. Medicine Powder Mixer Machine is easy to integrate with the upstream and downstream process, the problem of cross pollution and fly-dust caused by multi-material-transferring are solved. Various of material vessel might be equipped with this machine, so to meet the mixing requirement of large batch capacity, and multi-varities.

Principle:

Medicine Powder Blender is composed of frame, clamping type of rigid rotating shell (hereinafter called "rotating shell"), lift descend /clamp, drive, brake and control systems.

When start working, firstly, put the loaded square mixing bin (hereinafter called "bin") into rotating shell and a position signal will be sent by the control system when the bin fixed position. Press "confirm" key on the touch panel, the bin will be automatically raised in position and clamped by the lift descend /clamp system. After the bin fully clamped, the drive system starts blending according to the setting time and rotating speed. On achieving the set mixing time, the rotating shell slow down automatically, and brake system operates to stop the rotating shell vertically for moving the bin out easily and the blending task finished. Then the lift descend /clamp system work to lower the bin on the ground. Meanwhile, the printer will print out complete data of this batch. Finally, move out the bin from rotating shell and thus finish this blending cycle.

Medicine Powder Mixer Machine Feature
1. Medicine Powder Blending Machine is novel in design and has compact structure and nice appearance. The evenness of mixing achieves above 99% and the volume charge coefficient reaches 0.8.
2. Low rotating height, smooth running, reliable performance and easy operation.
3. Mirror polish for the inner and outer surfaces of the bin without dead corner, easy to unload and clean with no cross contamination, which conforms to the requirement of GMP.
4. The system controlled by PLC, sensor of photoelectric position control, and drive system which composed of motors, thus, can control the mixing time and unloading position. And when machine stopped, the discharge port will at the best position for unloading.
5. The locking clamp structure of loading cover bolt is easy for disassembly, cleaning and well sealing, and no leakage found in testing fill with water cover 80% of total volume.
6. Silicon soft connecting is used for connecting between inlet/outlet of the bin and other equipment, thereby, avoids flying dust.
7. The patented discharge butterfly valve is easy for disassembly, operation and cleaning with well sealing, and no leakage found in testing fill with water cover 80% of total volume. It has been used on thousands of blenders and well received by customers.

FZH Series Medicine Powder Blener Machine is ideal for powder and granules mixing applications in foodstuff industry with high mixing efficiency and without cross contamination and dust. Thus, the Medicine Powder Mixing Equipment can satisfy strict batch control and comply entirely with GMP requirements for medicine production.
This Medicine Powder Mixers can catch several kinds and different sizes of bins, which lifting, clamping, mixing, descending and clamp losing full automatically. One main machine can be configured with various bin specifications, thus it's the ideal blender for general mixing in pharmaceutical plant, meanwhile, widely used in chemical, light and food industries, etc.

Machine Parameter:

Model	FZH400	FZH600	FZH800	FZH1000	FZH1500
Max charge (L)	320	480	640	800	1200
Max charge (kg)	160	240	320	400	600
Power	4.75	7	7	8.5	10.5
Machine size	2460X2410X3200	2950X2860X3200	2950x2860x3500	3150×3030×3350	3260×3200×3650
Machine weight	1800	2500	2600	3000	3700

About Us:
From dryer, mixer to granulator, from unit machine to production line, we have them all. Erbang Drying is a professional manufacturer of industrial drying machine, mixing machine and granulating machine. Our flagship products include the hot air dryer, vibration fluid bed dryer, belt dryer, vacuum dryer, one dimensional mixer, two dimensional mixer, three dimensional mixer, and high speed granulator and so on. These high-performance machines have extensive applications within industries such as food, medicine and chemical. Sustained development and a strong emphasis on research and technology have bolstered our quality standards. we seek to achieve the highest level of customer satisfaction through professionally developed drying ,mixing and granulating solutions. Erbang Drying constant faith is providing perfect products to customer, excellenting service to customer !

Quality control

In order to ensure quality of product, we focus on user 's requirements and control improvement and enhancement quality of products .The quality assurance mainly focus on the processes of ensuring production readiness inspection, control of raw materials and components, process control, critical parts, important parts of quality control, assembly quality control, process control testing, measurement equipment control. Pay close attention to the implementation of the quality assurance work, strictly to three inspection system of self-checking, mutual inspection, special inspection. The key point of Quality assurance is focuses on critical parts, important parts of quality control, the quality standards required by ISO9000 quality control procurement documents in order to clarify its status and acceptance of quality standards for company's re-inspections ; For critical parts and important that the key processes of identification and corresponding technical documentation, control by "the implementation of key quality control process", and complete, accurate and complete original records. Difficulties in quality assurance is a special process control, quality assurance is mainly painting, has developed a special process (painting) process documents, take the appropriate technical measures, to quality assurance.

In the production process, we pay close attention to quality control of each process. Every component, every process was strictly controlled. Enhanced the quality inspection process, the establishment of the necessary quality control point, the process by a full-time staff and quality inspector for inspection and supervision. Improved testing procedures and operating instruction.

OUR SERVICES
Pre-sale service
We Invite customers to visit our company and communicate on technical requirements face to face.
Sale service
Responsible for debugging the equipment according to customers' requirements of various technical data. Our engineers will train our customers about equipment features and operation key points to make sure the equipment running in the best condition.
After-sale service
We provide installation, debugging, maintenance, training and other services (Optional); Provide relevant technical data, equipment, software and related GMP certification materials;Set up after-sales service hotline, and arrange personnel to visit customers every year to know more customer needs,like customer operation problems in the process of production equipment.
Quality promise
Our company promises strictly operate the ISO9001 quality system certification standards and pharmaceutical equipment GMP audit requirements,promise we provide new equipment. Advanced technology,good quality.Equipment operation safe reliable, affordable, easy to maintain.

Equipment warranty period is one year,all the parts for the equipment choose well-known brand.
During the warranty when equipment have problem in quality like equipment failure and damage, our company offer free maintenance or replacement.
