Solid Drink Granule Mixer
Main Features:
1.The Solid Drink Granule Mixing Machine features novel design, compact structure, and good appearance, the evenness of mixing reaches 99% , and the volume charge factor reaches 0.8.
2. Solid Drink Granule Mixing Equipment have smooth running, reliable performance, easy operation.
3. Solid Drink Granule Mixing Machinery have highly polished inner and outer surfaces of the barrel, no dead comer, easy to discharge materials, easy to clear, no cross contamination. Confining to the requirement of GMP.
Solid Granule Mixing Equipment is used for mixing of dry granulate material in pharmaceutical, food-stuff, chemical and other industries.
Brief Introduction:
V type high efficient asymmetric mixer, it is suitable for chemical, food, medicine, fodder, ceramics, metallurgy and other industries or granular material. The machine`s structure is reasonable, simple, closed operation, feeding and discharging material conveniently, (artificial or vacuum charging) barrel is made of stainless steel material, easy to clean, and can according to user requirements supporting forced mixer, for thin powder, block, containing certain moisture mixed material.
Principle and structure:
There is one set of motor and reducer at one end of the spiral mixer machine. The motor and reduce are connected by belts.
When the power on, the motor start work to drive reducer work ,The reducer rotate with the coupling to make the barrel rotary continuously, drive material inside the barrel runs up, down, left, right. This will achieve intensive mixing
Advantage:
The structure of this machine is unique.
Its mixing efficiency is high and no dead corner. It is made of stainless steel 304 /316L. Its inner and outer walls are processed through polishing. Its appearance is beautiful. Its mixing is uniform. Its scope of application is wide.
The forced stirrer can also be equipped, according to request of client, to meet the requirements of raw
materials like pretty fine powder, cake and certain moist stuff
About us
Hywell are machine ,food and chemical machniery manufacturer that from china, we are professional design and manufacture the drying machine, mixing machine and granulator machine, grinding machine, sterilization and so on that start from 2009.
The Main technical datum is for reference. We also produce and design product as per customers' requirement:
| Model of mixing machine | Capacity(m2) | Loading factor | Loading capacity(L) | Rotating speed(r/min) | Motor power(Kw) | Total weight(kg) | Model of vacuum pump |
| VH-0.1 | 0.1 | 0.4 | 40 | 15 | 1.1 | 180 | W2 |
| VH-0.3 | 0.3 | 0.4 | 120 | 15 | 1.5 | 350 | W2 |
| VH-0.5 | 0.5 | 0.4 | 200 | 15 | 1.5 | 550 | SK-1.5 |
| VH-1.0 | 1.0 | 0.4 | 400 | 12 | 3.0 | 1000 | SK-3 |
| VH--1.5 | 1.5 | 0.4 | 600 | 10 | 4.0 | 1100 | SK-3 |
| VH-2.0 | 2.0 | 0.4 | 800 | 10 | 5.5 | 1500 | SK-3 |
| VH-2.5 | 2.5 | 0.4 | 1000 | 8 | 7.5 | 1700 | SK-6 |
| VH-3.0 | 3.0 | 0.4 | 1200 | 6 | 7.5 | 1800 | SK-9 |
Quality control
In order to ensure quality of product, we focus on user 's requirements and control improvement and enhancement quality of products .The quality assurance mainly focus on the processes of ensuring production readiness inspection, control of raw materials and components, process control, critical parts, important parts of quality control, assembly quality control, process control testing, measurement equipment control. Pay close attention to the implementation of the quality assurance work, strictly to three inspection system of self-checking, mutual inspection, special inspection. The key point of Quality assurance is focuses on critical parts, important parts of quality control, the quality standards required by ISO9000 quality control procurement documents in order to clarify its status and acceptance of quality standards for company's re-inspections ; For critical parts and important that the key processes of identification and corresponding technical documentation, control by "the implementation of key quality control process", and complete, accurate and complete original records. Difficulties in quality assurance is a special process control, quality assurance is mainly painting, has developed a special process (painting) process documents, take the appropriate technical measures, to quality assurance.
In the production process, we pay close attention to quality control of each process. Every component, every process was strictly controlled. Enhanced the quality inspection process, the establishment of the necessary quality control point, the process by a full-time staff and quality inspector for inspection and supervision. Improved testing procedures and operating instruction.
OUR SERVICES
Pre-sale service
We invite customers to visit our company and communicate on technical requirements face to face. we also can do test in our lab for free. and then we will use the testing parameter to design final machine to reach client requirement.
Sale service
Responsible for debugging the equipment according to customers' requirements of various technical data. Our engineers will train our customers about equipment features and operation key points to make sure the equipment running in the best condition.
After-sale service
We provide installation, debugging, maintenance, training and other services (Optional); Provide relevant technical data, equipment, software and related GMP certification materials.
Quality promise
Our company promises strictly operate the ISO9001 quality system certification standards and pharmaceutical equipment GMP audit requirements,promise we provide new equipment. Advanced technology,good quality. Equipment operation safe reliable, affordable, easy to maintain.
Equipment warranty period is one year, all the parts for the equipment choose well-known brand.During the warranty when equipment have problem in quality like equipment failure and damage, our company offer free maintenance or replacement.
