Medicine Vacuum Drying Oven Feature
1.Under the condition of vacuum when use the Medicine Vacuum Drying Oven , the boiling point of raw material will decrease and make the evaporation efficiency higher. Therefore for a certain amount of heat transfer, the conducting area of dryer can be saved.
2.The heat source for evaporation may be low pressure steam or surplus heat steam.
The heat loss of Medicine Vacuum Tray Dryer is less.
3.Before drying, the treatment of disinfection may be carried out. During the period of drying, there is no impurity material mixed. It is in conformity with the requirement of GMP.
4.Vacuum Tray Dryer Oven belongs to static dryer. So the shape of raw material to be dried should not be destroyed.
Advantage
1.Under the condition of vacuum, the boiling point of material solution will reduce. It will increase impetus for heat and mass exchange. Therefore for certain heat exchange amount, it can save heat exchange area of evaporator.
2. The heat source for evaporating operation may be low pressure steam or waster heat steam (If having special requirement, customer may choose water or oil to heat. Our factory can design specially for you).
Suitable for drying thermal sensitive material that is easy to decompose, polymerize or denature.
Before drying, it can carry out disinfections. During the period of drying, any impurity can't be mixed into it.
It is static vacuum dryer, the form and structure of material to be dried can't be damaged.
Main technical parameter:
| Model | YZG-600 | YZG-1000 | YZG-1400 | FZG-15 |
| Weight of drying chamer(kg) | 350 | 800 | 1400 | 2100 |
| Layers of baking shelf | 4 | 6 | 8 | 8 |
| Dimensions of baking tray(mm) | 310x600x45 | 460x640x45 | 460x640x45 | 460x640x45 |
| Number of baking tray | 4 | 12 | 32 | 32 |
| Temp inside chamber(ºC) | ≤ 150 | ≤ 150 | ≤ 150 | ≤ 150 |
| Vacuum at idle inside chamber(Mpa) | ≥0.092 | ≥0.092 | ≥0.092 | ≥0.092 |
| Type and power of vacuum pump if condersateor used | 2X-15A 2KW | W3 5.5KW | W3 5.5KW | 2X-70A 5.5KW |
| Tyoe and power of vacuum pump if no condersator used | SK-0.8 2.2KW | SK-3 7.5KW | SK-3 7.5KW | SK-3 7.5KW |
From drying machine, mixing machine to granulation machine, from unit machine to production line, we have them all. Erbang Drying is a professional manufacturer of industrial dryer, powder mixer and granulation machine. Our flagship products include the drying oven, fluid bed dryer, belt dryer, vacuum dryer machine, rotary flash dryer, chamber drying machine, single dimensional powder mixer, three dimensional mixer, two dimensional mixer and high shear granulation machine, continuous granulator and so on. These high-performance machines have extensive applications within industries such as food, medicine and chemical. Sustained development and a strong emphasis on research and technology have bolstered our quality standards. we seek to achieve the highest level of customer satisfaction through professionally developed drying, mixing and granulation solutions. Erbang Drying constant faith is providing perfect products to customer, excellenting service to customer !
