Round Vibrating Separator Machine
1. For the electrical component of Circular Vibrating Sieve , we mainly use international brand such as ABB ,Siemens or Schneider.
2. The Round Vibrating Separator often connect with drying machine, such as vibration fluid bed dryer, fluid bed dryer and so on.
3. The Vibrating Separator Equipment also connect with grinding machine such 30B grinding machine to make the big size materials into small pieces.
Vibrating Separator Equipment Principle of the structure
ZS series Round Vibrating Sieve Machine use upright motor as the source of vibration equipped eccentricity hammer on the both sides of motor, change circumrotate to level, upright and incline movement, then pass these three movement to the surface of the screen. Adjust the phasic angle on the both sides of the top and bottom to change the movement orbits of the surface screen.
Main Features:
1. High efficiency, refined design, duration, any powders and mucilage are suitable for using.
2. Easily to replace the screen, simple operation and convenience washing.
3. Never jam the hole meshwork, no powder flying, filter size of the powder between 500 mesh and 0.028 mm.
4. Discharge the impurity and coarse materials automobile and operates continuously.
5. Unique screen flame design, long duration of screen, only 3-5 to replace the screen.
6. Small volume, move easily.
7. The highest layers of the screen are about 5 layers. But 3 lagers are suggested.
Attention to order
1. When inquiry the ZS series vibration sieve, Client need to supply the materials name.
2. When inquiry the ZS series vibration sieve, Client need to supply the materials characteristic that include materials HP and so on.
3. When inquiry the ZS series vibration sieve, Client need to supply how much kinds materials size need to separated
4. When inquiry the ZS series vibration sieve, Client need to supply the each kinds separated materials size.
5. When inquiry the ZS series vibration sieve, Client need to decide which kinds steel for machine-304 stainless steel or 316L stainless steel (Erbang also give suggestion for the stainless steel model base the materials HP).
About Erbang Drying:
Erbang are medicine, food and chemical machinery manufacturer that from china, we are professional design and manufacture the drying machine, mixing machine, and granulator machine, grinding machine and so on that start from 2009. we approved the CE, ISO, GMP.
Erbang ensures you to the best quality services at all times. Shall you need any further information, please do not hesitate to contact undersigned.
| Model | capacity | Sieve hole | Power (vibration motor) | Power (common motor) | Vibration frequency | Weight |
| ZS-400 | 50-300kg/h | 3-200mesh | 0.18kw | 0.55kw | 1400r/min | 150kg |
| ZS-600 | 100-450kg/h | 3-200mesh | 0.25kw | 0.75kw | 1400r/min | 250kg |
| ZS-800 | 300-750kg/h | 3-200mesh | 0.55kw | 1.1kw | 1400r/min | 320kg |
| ZS-1000 | 400-1100kg/h | 3-200mesh | 1.1kw | 1.5kw | 1400r/min | 400kg |
| ZS-1200 | 600-1600kg/h | 3-200mesh | 1.1kw | 1.5kw | 1400r/min | 500kg |
| ZS-1500 | 800-1800kg/h | 3-200mesh | 1.5kw | 2.2kw | 1400r/min | 600kg |
| ZS-1800 | 1000-2000kg/h | 3-200mesh | 3.0kw | 3.0kw | 1400r/min | 800kg |
| ZS-2000 | 1300-2500kg/h | 3-200mesh | 3.0kw | 3.0kw | 1400r/min | 1000kg |
