CNC Sealant Sealing Robot for Insulating Glass
Machine Performance Introduction
1.High sealing performance, high automation, reduce labor cost, save manpower cost, improve production efficiency
2.Fully intelligent and smart HMI in touching screen, with memory function and easy operation
3.Best sealing quality without air bubbles, smooth surface, avoid time for corner correction
4.For Model ll: Using two sealant supply systems, switch fast and one-key operation
5. The width of machine is 1.4m, small floor area, save space.
6. The smallest insulating glass size can be processed is 300 X 300mm
7. Equipped with anti blocking device in the mixer, easy to clean
8.Servo control system adopts world famous brand (Japan YASKAWA ), the performance is stable, counting speed is fast, sealant output with high precision, surface with high smoothness.
9.Shaft transmission to make the glass being transferred smoothly with accurate positioning.
10.Special V type transmission belt to avoid the sealant sticking on the belt, ensure the glass edge clean, V type block is changeable
11.The spare parts are produced with high standardization and high precision, ensure the machine can be used with long-term stability
12.Suitable for triple glazing.
13.Conveying wheel on backboard adopts embedded wheel, to make sure the glass be transported smoothly
14.Equipped with high speed positioning function, glass can be located accurately when transport fast.
15.Touch screen adopt Ethernet communication, sensitive operation, suitable for popular operation
16.Keep machine service and upgraded timely with our own R&D departments
Main Technical Parameters
|
Model |
ZNJ2540-I |
ZNJ2540-II |
|
Voltage Power |
380V 50Hz 9KW |
380V 50Hz 9KW |
|
Air Pressure |
0.6-0.8Mpa |
0.6-0.8Mpa |
|
Squeeze Pressure |
32Mpa |
32Mpa |
|
Max Glass Size |
2500*4000mm |
2500*4000mm |
|
Min Glass Size |
300*300mm |
300*300mm |
|
Glass Thickness |
12-56mm |
12-56mm |
|
Working Speed |
5-40m/min |
5-40m/min |
|
Overall Dimension |
8630*1400*3500mm |
8630*1400*3500mm |
