Insulating Glass Production Line
Machine Performance Introduction
1.Outside and inside assembly program, comprehensive function
2. Automatic numerical control insulating glass production line, automatic identification LOW-E
3. Siemens PLC control. touch sensitive screen man machine interface
4. Adopt imported vacuum generator and sucker resulted in perfect suction effect to the glass
5. Produce the step IG unit and triple glass production according to the customers' different request
6. Full distance automatic changeable frequency speed adjustment, which can save work waiting time and improve production efficiency.
|
Model |
LBJ2536 |
|
Input Voltage |
380V 50HZ |
|
Total Power |
34kw |
|
Max Glass Size |
2500*3600mm |
|
Min Glass Size |
300*500mm |
|
Glass Thickness |
3-12mm |
|
Working Speed |
8-45m/min |
|
Total Weight |
7000kgs |
|
Outside Dimension |
26000*1800*3600mm |
If you are interested in the product, contact 2bvideo.com for more information for more information
