Hydraulic breaker
Hydraulic breaker is a type of construction machinery that is mounted on excavators, backhoes, skid steers, mini-excavators, and stationary plants. Driven by hydraulic power it breaks rocks into smaller sizes or demolishes concrete structures into manageable pieces.
According to the difference of the hydraulic breaker structure, we mainly categorize it as side type breaker (side mounted breaker), top type breaker (top mounted breaker) and silence type breaker (also called box type or low noise type).
The silence type hydraulic breaker adopts full-closed housing design, it can protect the main body from damage. What’s more, the full-closed box design can reduces noise up to 50%.
In the application, the silence type hydraulic breaker is more eco-friendly than side type hydraulic breaker and top type hydraulic.
Based on different application and purpose, you could select different type hydraulic breaker (hydraulic hammer) to meet with demands. Please feel free to contact with us to get more information about hydraulic breakers.
WYB Hydraulic Breaker Features:
• Available for 0.8 - 75 Ton any brand excavators.
• Simplicity in construction, easy to use and maintain
• Most advanced processing equipment and technology
• One to two-year warranty
• Long service life
• 24 hours online after-sales service
• Application
Mining------------Mining,Second-time breaking
Metallurgy-------Clearing slag,Demolition of furnace and foundation
Road------------- Repairing,Breaking,Foundation work(asphalt road)
Railway----------Tunneling,Demolition of bridge
Construction----Demolition of building and reinforced concrete
Ship repairing--Clearing clam and rust from the hull
Others----------- Breaking frozen mud
Hydraulic Rock Breaker Types:
Generally,we have 3 types of hydraulic breaker, side type installation rock breakers, top type installation hydraulic rock breaker and silent type rock breaker.Please choose the type you like, we'll try to meet all of your requirements.
The silence type hydraulic breaker adopts full-closed housing design, it can protect the main body from damage. What's more, the full-closed box design can reduces noise up to 50%.
In the application, the silence type hydraulic breaker is more eco-friendly than side type hydraulic breaker and top type hydraulic.
Our breaker can be customized to fit varisized excavators, pls contact us for the more information.
What is the difference among side type,box type and top type rock breakers?
For Side type, the installation pins are on the side of the breaker.
For Top type , the installation pins are on the top of the rock breaker.
And for box type, the rock breaker bracket is full sealed like a box,and it equiped with rubber cushion inside of the bracket to keep lower noise. So it is also called silence type rock breaker.The installation pins are also on the top for silent type rock breaker, same as top type installation way on the excavtors. Both side type and top type breakers are with opening bracket, which is easy for maintenance and parts exchanging. But for box type rock breaker, it has to open the box and move out the main body to do maintenance job.
How is the quality?
We are offering OEM service for some famous brands from Italy, Germany,Turkey .South Korea etc.who are selling our hydraulic breakers with their brands all over the world.
How is the price?
Factory direct price, Not the lowest,but reasonable and acceptable,so we are manufacturing and selling and shipping in a very large quantity .
You are welcome to visit our grand factory.
Technology Parameters:
1) WYB SB series hydraulic hammers
| Decription/Model | WYB400T | WYB450T | WYB530T | WYB680T | WYB750T | WYB1000T | WYB1250T | ||
| Total Weight | kg | 100 | 110 | 256 | 336 | 454 | 988 | 1,410 | |
| Operating Pressure | (bar / psi) | 90-120 | 90-120 | 90-120 | 110-140 | 120-150 | 150-170 | 150-170 | |
| Required oil flow | (l/ min) | 15-25 | 20-30 | 20-50 | 40-70 | 50-90 | 80-110 | 90-120 | |
| Tool Diameter | mm | 40 | 45 | 53 | 68 | 75 | 100 | 125 | |
| Impact Rate | (bpm) | 800-1400 | 700-1200 | 500-1000 | 500-900 | 400-800 | 350-700 | 350-650 | |
| Hydraulic Hose | inch | 1/2" | 1/2" | 1/2" | 1/2" | 1/2" | 3/4" | 1" | |
| Carrier weight | tons | 0.8-2.5 | 1.2-3 | 1.0-3.5 | 4 ~ 7 | 6 ~ 9 | 11 ~ 15 | 15-18 | |
| Decription/Model | WYB1350T | WYB1400T | WYB1400AT | WYB1500T | ||
| Total Weight | kg | 1,863 | 2,142 | 2,162 | 2,400 | |
| Operating Pressure | (bar / psi) | 160-180 | 160-180 | 160-180 | 160-180 | |
| Required Oil Flow | (l/ min) | 100-150 | 120-180 | 120-180 | 130-190 | |
| Tool Diameter | mm | 135 | 140 | 140 | 150 | |
| Impact Rate | (bpm) | 350-600 | 350-500 | 350-500 | 300-450 | |
| Hydraulic Hose | inch | 1" | 1" | 1" | 1 1/4” | |
| Carrier Weight | tons | 18 ~ 21 | 20 ~ 26 | 20 ~ 26 | 25 ~ 28 | |
| Decription/Model | WYB1550T | WYB1650T | WYB1750T | WYB1850T | WYB1900T | WYB1950T | WYB2000T | ||
| Total Weight | kg | 2,660 | 3,200 | 3,788 | 4,720 | 4,800 | 4,900 | 6,300 | |
| Operating Pressure | (bar / psi) | 160-180 | 160-180 | 160-190 | 190-220 | 190-220 | 190-220 | 200-230 | |
| Required oil flow | (l/ min) | 180-240 | 200-260 | 210-290 | 220-260 | 220-260 | 280-320 | 280-360 | |
| Tool Diameter | mm | 155 | 165 | 175 | 185 | 190 | 195 | 200 | |
| Impact Rate | (bpm) | 350-450 | 250-400 | 200-350 | 180-350 | 180-350 | 180-350 | 150-300 | |
| Hydraulic Hose | inch | 1 1/4” | 1 1/4” | 1 1/4” | 1 1/4” | 1 1/2” | 1 1/2” | 1 1/2” | |
| Carrier weight | tons | 28 ~ 35 | 30 ~ 40 | 40 ~ 55 | 45-55 | 45-55 | 55-65 | 65-75 | |
