API IIB AISI4140/4130 Sucker rod coupling
Spraying alloy powder on sucker rod coupling doubles the rate of surface hardness; and extends a longer service life.
Specifications of Sucker Rod Coupling
|
Type |
Model |
OD mm |
Width of Wrench Square mm
|
Length of Wrench mm |
Rounding chamfer θ |
|
T Grade Coupling |
5/8 |
Φ38.1+0.13 -0.25 |
34.9 0 -0.8 |
31.8+0.62 0 |
45° |
|
3/4 |
Φ41.3+0.13 -0.25 |
38.1 0 -0.8 |
31.8+0.62 0 |
||
|
7/8 |
Φ46.0+0.13 -0.25 |
41.3 0 -0.8 |
31.8+0.62 0 |
||
|
1 |
Φ55.6+0.13 -0.25 |
47.6 0 -0.8 |
38.1+0.62 0 |
Mechanical Property
|
Grade |
Material |
Yield PointMPa |
Tensile strength MPa |
Extension Radio % |
Reduction of cross-section % |
Izod Impact toughness J |
|
D |
High Quality Alloy Steel |
≥620 |
793~965 |
≥10 |
≥50 |
≥60.8 |
We also provide Sub-coupling: 5/8-3/4 T(SM), 3/4-7/8T(SM), 7/8-1T(SM), 1-1 1/8 T(SM).
If you are interested in the product, contact 2bvideo.com for more information for more information
The information of 2bvideo.com limited shown above is provided by the user or collected on the network. Video 2B does not guarantee the authenticity,accuracy and legitimacy of 2bvideo.com limited information. Video 2B does not involve legal relationships and disputes between users arising from transactions other than secured transactions on this website. Disputes shall be settled by you through negotiation. If you are the person in charge or relevant employee of this enterprise, if you find that the enterprise information is incorrect or want to manage thiscompany, please contact us jacklee1558@gmail.com, after you claim the enterprise, you can obtain management permission, publish supplyand demand information, bring consulting orders, and remove page advertisements.
Main Product:
Sucker Rod,
Sucker Rod Centralizer,
Sucker Rod Guide,
Downhole Tools,
Tubing Centrazlier ,
Sucker Rod Coupling
