Porous Copper Custom Shaped Cu Sintered Filter
I. Product Introduction
The copper powder sintered element is made of copper alloy powder through high-temperature sintering. It has high filtration precision, good air permeability, high mechanical strength, high material utilization rate, and is suitable for relatively high working temperatures and can withstand thermal shock. It is widely used in pneumatic components, chemical engineering, environmental protection and other fields. Porous elements of various shapes, structures, different particle sizes and porosities can be produced according to user requirements, such as: cover, cap, sheet, tube, rod-shaped filter elements.
II. Technical Characteristics
1. High filtration precision, stable pores, and the phenomenon that the pore size changes with pressure will not occur. It can effectively remove suspended solids and particles, etc. It has excellent filtration precision and good purification effect. The pore sizes are 5-15, 15-25, 25-40, 40-60, 60-100 microns, and the size is determined according to customer needs.
2. Good air permeability and low pressure loss. The filter element is completely composed of spherical powder, with high porosity, uniform and smooth pore size, low initial resistance, easy back-blowing, strong regeneration ability, and long service life.
3. High mechanical strength, good rigidity, good plasticity, oxidation resistance, corrosion resistance. There is no need for additional skeleton support and protection. It is simple to install and use, convenient to maintain, has good assembly performance, and can be welded, bonded and mechanically processed.
4. Uniform pores, especially suitable for occasions with high requirements for uniformity such as fluid distribution and homogenization treatment.
5. The copper powder sintered product is formed in one step without cutting, with high effective utilization rate of raw materials, which can save materials to a greater extent, especially suitable for components with large batches and complex structures.
III. Product Features
Porous elements of various shapes, structures, different particle sizes and porosities can be produced according to user requirements, such as: cover, cap, sheet, tube, rod-shaped filter elements. The product has the characteristics of high filtration efficiency, high tensile strength, high temperature resistance, corrosion resistance, etc., and is suitable for working conditions in different environments. It is used as a filter element for gases and liquids. The size is determined according to customer needs.
IV. Product Applications
It is used for purification equipment required for the purification of original ecological resources and the recycling of resources. Currently, the filter elements are mainly used in the filtration industry such as oil filtration, air filtration, water filtration, and air filtration. It can remove a small amount of solid particles in liquids or air, and can protect the normal operation of equipment or the cleanliness of the air. When the fluid enters the filter element with an appropriate specification of the filter screen, the impurities are blocked, and the clean fluid flows out through the filter element. It is also used for the medium purification and flow restriction of pneumatic components, lubricating oil, fuel oil, and hydraulic and pneumatic systems, oil removal and purification of compressed air, sand removal filtration of crude oil, filtration of nitrogen and hydrogen (sulfur-free), pure oxygen filtration, bubble generators, and gas distribution in fluidized beds.
V. Other Products
We specialize in the production of sintered filter elements, sintered filters, sintered mesh filter elements, powder metallurgy products, gears, and metal injection molding (MIM), including: powder sintered filter elements, stainless steel sintered mesh, powder sintered filters, powder sintered filter sheets, stainless steel powder sintered filter elements, stainless steel mesh sintered filter elements, stainless steel powder sintered filters, stainless steel sintered filter sheets, melt filter elements, sintered mesh filter sheets, bronze powder sintered filter elements, metal powder sintered filter elements, copper powder sintered filter elements, stainless steel sintered filter elements, copper powder sintered filter elements, filter cartridges, filter sheets, filter tubes, bronze powder sintered filters, powder metallurgy filters, microporous sintered filters, copper ball sintered filter elements, copper bead sintered filter elements, copper powder sintered filters, stainless steel powder metallurgy sintered filters, filters, bronze sintered filters. Our company can customize and produce a variety of special-shaped and high-precision parts according to your design requirements. Welcome to send us drawings and samples for customization.
