triangle folding with winder DZ-1650
Main Technical Parameters
1. Folding Material:
10-150μm, POF / HDPE / LDPE / CPP / BOPP
2. Maximum machine speed: 400 m/min; Normal running speed
300 m/min; Machine running stable, non-obvious vibrate and noise.
3. Unwind Max. Load-bearing: 1000KG;
4. Max. Unwind diameter: 1000 mm.
5. Max. Unwind
width: 1650mm
6. Min. Unwind width: 400mm.
7. Rewind Max. Diameter: 1000 mm
8. Max. Rewind
width: 850mm
9. Min. Rewind
width: 200mm.
10. Unwind rolling core: 3-inch and 6-inch chuck
11. Rewind rolling core: 3-inch and 6-inch paper-core
12. Rewind neatness ＜ 1 mm
13. Machine total
power: 600 V AC, 3 phase, 60 Hz, Total power: 45KW
14. Air-source air pressure ＞ 5 kg/cm2
3.15. External dimension: 3300mm x 3200mm x 2500mm (L x W x
H)
16. Machine dead load: About 6Tons
If you are interested in the product, contact 2bvideo.com for more information for more information
The information of 2bvideo.com limited shown above is provided by the user or collected on the network. Video 2B does not guarantee the authenticity,accuracy and legitimacy of 2bvideo.com limited information. Video 2B does not involve legal relationships and disputes between users arising from transactions other than secured transactions on this website. Disputes shall be settled by you through negotiation. If you are the person in charge or relevant employee of this enterprise, if you find that the enterprise information is incorrect or want to manage thiscompany, please contact us jacklee1558@gmail.com, after you claim the enterprise, you can obtain management permission, publish supplyand demand information, bring consulting orders, and remove page advertisements.
Main Product:
Slitting machine,
Casting film Lines,
Extrusion coating machine,
Paper core cutting machine ,
Primary slitters,
slitter machine
