Split-unit 3 Arm Hand Hydraulic Bearing Puller
Technical Parameter
a. Hydraulic gear puller can not only save time but also can ensure highest efficiency.
b. It can be widely applicable in car maintenance factories and mechanical factories.
c. It can be used for any machines which have bearing, belt pulley, motor and gear.
d. It is applied to the pulling operation of gear, belt pulley, bearing or other wheels in car maintenance factories, mechanical factories and repair workshops.
e. Detached wheel pulling tool can be connected to hydraulic manual pump, its portable structure is easy for carrying and operation.
f. Using hydraulic gear puller is convenient for operating.
g. Operators can exchange two jaws and three jaws as required in the working spot immediately.
h. The puller can be touched the working center quickly after rotary according to the distance between the puller and piston center.
i. Pump can be chosen freely.
j. The 3-jaw types can be adjusted from high to low point.
|
Model |
EC-ZYD-5 |
EC-ZYD-10 |
EC-ZYD-20 |
EC-ZYD-30 |
EC-ZYD-50 |
EC-ZYD-100 |
|
Capacity(T) |
5 |
10 |
20 |
30 |
50 |
100 |
|
Process(mm) |
50 |
50 |
60 |
60 |
60 |
105 |
|
Claw Number |
3 |
3 |
3 |
3 |
3 |
3 |
|
Spread(mm) |
50-200 |
50-250 |
100-350 |
150-400 |
200-500 |
300-600 |
|
G.W(kg) |
15 |
20 |
27 |
35 |
55 |
150 |
|
Volume(cm) |
73*18*18 |
73*18*18 |
73*21*18 |
73*25*18 |
73*25*18 |
103*70*23 |
To support the Transmission work, Marshine Power has Tubular Gin Pole, Come Along clamp, wire rope pulley block, nylon sheave hoisting tackle, hydraulic cable puller and tensioner ,conductor installation devices all are OEM and professionally produced per ISO 9001:2008, which are being sold to over more than 50 countries in the world. Some items like emergency restoration tower and crossing structure, we can customized, and the safety tools and accessories, are not demanded the MOQ. You can freely help you out either Tech issue or Products requirements. Pls approach us. Thanks.
