31Metre Straight Boom Lift

2 week ago

0 0

Xuzhou Acedo Import and Export Co., Ltd

 3 month year

Product details

31M aerial work platform

I. Main technical parameters

· Total length: 5995 mm

· Overall width: 2060mm

· Overall height: 2780 mm

weight

· Seat capacity (including driver) : 2 people

· Total vehicle weight: 4495 kg

performance

· Rated load of working platform: 200kg

· Maximum working height: 31 meters

· Maximum working range at maximum height: 25m

· Maximum operating range: 78°

· Maximum working range Working height: 5 meters

· Leg span (fully extended) : 4,630 mm (transverse) x 5,040 mm (longitudinal)

· Working platform rotation: ±360°

Prosperous operation

· Boom elevation rise time: 55≤t≤65s

· Height reduction time of boom: 50≤t≤60s

· Full extension time of boom: 70≤t≤80 s

· Full retracting time of boom: 60≤t≤70 s

· Boom speed: 140≤t≤150 s/r

Discharge operation

· Horizontal leg extension time: 20≤t≤30 s

· Horizontal leg retracting time: 15≤t≤25s

· Vertical leg extension time: 20≤t≤30 seconds

· Vertical leg retracting time: 10≤t≤20 s

· Leg expansion and retracting time: 30≤t≤50 s

Parameters of travel

Front/rear overhang/rear extension: 1,075mm / 1,800mm / 308mm

· Wheelbase: 2800 mm

· Maximum driving speed: 100 km/h

· Minimum ground clearance: 181 mm

· Approach/departure Angle: 19°/ 13°

2. Configuration description

Base plate

· Model: Gangneung Sundak six-level power steering chassis

engine

· GB VI 122 HP engine: maximum power 90kw; 2 people single row cab; Equipped with air conditioning and radio

Guardrail and walkway

· Materials: stainless steel toolbox, aluminum alloy anti-slip walkway, stainless steel guardrail

Power output system

· Operation mode: pneumatic control; Gear pump is connected directly to the PTO

Work platform

· Size: 1600 × 700 × 1000mm

· Rated load: 200kg

· Type: two-person steel platform (can be extended to 2 meters)

Structure of prosperity

· Type: synchronously extended seven-section 17-sided boom

Hydraulic system

· Hose configuration: external roller (Italian full extension)

Rotating mechanism

· Turntable rotation: ±360° continuous rotation

· Working platform rotation: ±360°

Stable support

· Type: Front v type, rear v type, adjustable independently

Control system

· Turntable: hydraulic lever operation; Standard wireless remote control

· Lower control: hydraulic lever operation; Equipped with emergency electric hydraulic pump

Equilibrium system

· Type: Hydraulic balance system

We independently design and manufacture the following four major product categories:Lifting Machinery: Truck crane, folding boom and straight boom truck-mounted crane, spider crane, rough-terrain crane, and fast-erecting tower crane.
