Constant current source:
Technical characteristics:
1. AC constant current source is specially designed and manufactured for low-voltage electrical appliance users. Its output current is constant, and its output waveform is pure sine wave. It can carry resistive, inductive and capacitive loads, meet the requirements of low-voltage electrical appliances for test power supply, and can be used as an over-current test instrument.
2. Outstanding advantages, high current stabilization accuracy, can be used according to the user's environment. Ensure constant output current.
3. Automatic test of different current levels can be carried out (items: voltage, current, frequency, lifting time, and cyclic test operation)
4. Frequency adjustable range: 40-500HZ (optional), fixed output: 50HZ, 60HZ (fixed output frequency within more ranges can be designed according to user requirements)
Product application:
1 AC air switch
2 AC contactor
3 Mechanical switch and electronic switch
4 Cable and wire
5 Automatic detection and calibration platform
6 Large current capacitor electrical appliances
7 Thermal relay, molded case circuit breaker, small circuit breaker and the required rated current, action current, short-circuit protection current, etc
Technic parameter:
|
Model |
XYH50-3110000 |
|
Capacity |
1000kVA |
|
Input |
|
|
Input mode |
3P4W+PE |
|
Input voltage |
380V（±15%） |
|
Input frequency |
50Hz/60Hz（±10%） |
|
Input current harmonic |
THDi≤4% |
|
Power factor |
≥0.99 |
|
Output |
|
|
Output mode |
1P2W |
|
Output voltage |
Phase voltage: low range: 0-50V, high range: 0-100V |
|
Output frequency |
50Hz/60Hz |
|
Output current |
Low grade: 20000A, high grade: 10000A |
|
Output frequency stability |
≤0.01% |
|
Output current harmonic |
THDi≤3% |
|
Power efficiency |
≥85% |
|
Protection function |
Output overvoltage/undervoltage, overcurrent, overload, input overvoltage/undervoltage, high temperature, short circuit protection等 |
|
Display and communication |
|
|
Display function |
7-inch LCD display |
|
Communication function |
RS485 (standard configuration)/RS232 (optional)/Ethernet port (optional) |
|
Operating environment |
|
|
work environment |
24 hours of non-stop operation at ambient temperature of - 5 ℃ - 45 ℃ and relative humidity of 0-95% |
|
Degree of protection |
IP21 |
|
Cooling mode |
Forced fan |
|
Altitude |
≤2000m |
|
Other performance |
|
|
Compressive strength |
AC1500V/1min/10mA |
|
Insulation resistance |
≥100MΩ |
|
Noise |
≤75dB(A) |
|
Dimensions (W * D * H) |
3100*900*2080mm， |
Accept customization
