Work Principle of Large Tomato Jam Paste Grinding Production Line:
This tomato paste grinding machine used in the disintegration of solid particles or droplet size of a liquid present in suspension or emulsion. The machine consists an inlet (which is subjected to a tremendous shearing action that effects a time dispersion of uniform size) and an outlet. Colloid mill works on the rotor-stator principle. The equipment breaks down materials by forming dispersion of material in a liquid. Shearing takes place in a narrow gap between a static cone (the stator) and a rapidly rotating cone (the rotor). To reduce wear, the rotor and stator are constructed using 3Cr13 food grade stainless steel.
If you want to use this colloid mill into production line, we can provide the horizontal type colloid mill.
Technical Parameters:
| Model |
Power |
Capacity |
Rotation |
Rotor Dia. |
Dimenison |
Weight |
|
GMS-JT50 |
1.1kw |
10-30kg/h |
2820rpm |
50mm |
520*250*555mm |
67kg |
|
GMS-JT80 |
4kw |
70-100kg/h |
2890rpm |
80mm |
685*335*928mm |
173kg |
|
GMS-JT110 |
7.5kw |
200-300kg/h |
2930rpm |
110mm |
700*430*1000mm |
235kg |
|
GMS-JT130 |
15kw |
400-600kg/h |
2930rpm |
130mm |
975*456*1054mm |
330kg |
|
GMS-JT180 |
22kw |
800-1000kg/h |
2930rpm |
180mm |
981*476*1124mm |
420kg |
|
GMS-JT240 |
45kw |
1500-2000kg/h |
2970rpm |
240mm |
1319*500*1276mm |
1000kg |
|
GMS-JT300 |
75kw |
3000-4000kg/h |
2970rpm |
300mm |
1400*620*1400mm |
1600kg |
What is more, we also have the fruit vegetable washing machine, fruit vegetable crusher, fruit vegetable juice extrator and hydraulic press machine to make tomato juice.
Wooden Package & Exporting Cases:
We exported to USA, Portugal, Australia, Ecuador, Chile, South Africa, Panama, Netherlands, Greece, Zambia etc more than 30 countires. We promise export standard free fumigation wooden box.
We also have the tomato washer machine:
