LFR 30m Short Range Laser Rangefinder Module
Laser rangefinder module is mainly designed for laser distance measurer as the core part of a laser rangefinder, laser tape measure.
JRT LRF 30m laser module responds much quicker with high accuracy.
For different range measuring program, our modules can satisfy customers different requirements
30m Short Range Laser Rangefinder Module can be multifunctional, such as :
Height/Distance/Area/Volume/Pythagorean Measurement. Voice, Bluetooth, angle measuring, beep, and any other functions can be customized.
We have been in this laser line for over 15 years, with a strong R&D ability through unremitting efforts, we are now growing a leading supplier of LFR Laser Rangefinder Module
in China and oversea market.
Specifications
|
Accuracy |
±1 mm (0.04 inch) |
|
Measuring Unit |
meter/inch/feet |
|
Measuring Range (without Reflection) |
0.03-30m |
|
Measuring Time |
0.4~4 seconds |
|
Laser Class |
Class II |
|
Laser Type |
635nm, <1mW |
|
Size |
41*17*7mm (±1 mm) |
|
Weight |
About 4g |
|
Voltage |
DC2.0~3.3V |
|
Electrical Level |
TTL/CMOS |
|
Frequency |
3Hz |
|
Operating Temperature |
0-40 ℃ (32-104 ℉ ) |
|
Storage Temperature |
-25~60 ℃ (-13~140 ℉) |
Product Specifications
1.Under bad measure condition, like environment with strong light or the diffuse reflectance of measuring point over-high or low, the accuracy would have bigger amount of error: ±1 mm+40PPM.
2.Under strong light or bad diffuse reflectance of target, please use a reflector.
3.Operating temperature -10 ℃~50 ℃ can be customized.
4.U81 supports multi-slaves network.
U81 30m Accurate Laser Distance Measuring Sensor Modules
Laser distance meter module is mainly designed for laser distance measurer as the core part of a laser rangefinder, laser tape measure. JRT module responds quickly with high accuracy and long range measuring.
For different range measuring program, our modules can satisfy customers different requirements, 30m, 40m, 60m, 80m, 100m, 120m, 150m, each distance can be multifunctional, such as :Height/Distance/Area/Volume/Pythagorean Measurement. Voice, Bluetooth, angle measuring, beep, and any other functions can be customized.
We have been in this laser line for over 15 years, with a strong R&D ability through unremitting efforts, we are now a leading supplier of laser distance meter modules in China.
30m Short Range Laser Rangefinder Module
