Durable Hydraulic Tail Lift Liftgates QWB 1000KG
Product description:
Automobile tailboard is also called car lifting tailboard, car loading and unloading tailboard, lifting tailboard, and hydraulic car tailboard. It is a hydraulic lifting loading and unloading equipment powered by on-board battery installed in the tail of trucks and various vehicles. Automotive tail plates are widely used in aerospace, military, fire protection, postal, financial, petrochemical, commerce, food, medicine, environmental protection, logistics, manufacturing and other industries. It can greatly improve the efficiency of transportation and loading and unloading, and save costs. It is one of the modern logistics transportation equipment.
Features:
■ Fast: Just control the lifting and lowering of the tailboard by operating the buttons, and the goods can be easily transferred between the ground and the carriage.
■ Safety: The use of tailgate can make cargo loading and unloading easy without manpower, improve the safety of operators, and reduce the damage rate of items during loading and unloading, especially flammable, explosive, and fragile items, which are more suitable for tailboard loading and unloading.
■ Efficient: use tailboard for loading and unloading, free of site and personnel restrictions, one person can complete loading and unloading. It can effectively save resources, improve work efficiency, and give full play to the economic efficiency of the vehicle.
Scope of application:
The tailboard has the characteristics of fast, safe and efficient, which can greatly improve the efficiency of transportation and loading and unloading, and it is one of the modern logistics transportation equipment. It is widely used in logistics, postal, tobacco, petrochemical, commerce, finance, manufacturing and other industries.
Specifications：
|
Platform size(mm) |
1700X1600 |
NL -QWB1.5 1800X1600 |
NL-QWB2.0 2000x1800 |
2300x1800 |
It can be made according to the customer"s damands. |
|
1800x1600 |
1800x1700 |
2100x1800 |
2400x1800 |
||
|
1800x1700 |
1900x1700 |
2200x1800 |
2500x1800 |
||
|
1 900x1700 |
(I1 can be made according the width of different vehicle) |
||||
|
Capacity(kg) |
1000 |
1500 |
2000 |
2500 |
1 |
|
Self weight(kg) |
350 |
450 |
500 |
550 |
1 |
|
Motor power(kw) |
1.6 |
1 .6/2.2/2.5 |
2.2/2.5 |
3 |
1 |
|
Motor |
DC12V-24V/100AH- 160AH |
1 |
|||
|
Frame arm length(mm) |
750 |
750/900 |
900 |
900 |
1 |
|
Frame inner width (mm) |
846/948 |
846/948 |
948 |
948 |
1 |
|
Height from vehicle box to ground(mm) |
700-1050 |
700-1550 |
1050-1550 |
1050-1 550 |
1 |
|
Average lifting speed (mm/sec) |
60-80 |
60-80 |
60-80 |
60-80 |
Speed can be controlled |
|
Hydraulic oil |
46# Hydraulic oil |
1 |
|||
|
Platform working angle |
5°-9° |
5*-9* |
5*-9° |
5*-9° |
1 |
