Manual Forklift Manual Pallet Stacker
Product Overview
The manual hydraulic lifting truck is a kind of dynamic and pollution-free manual hydraulic stacking truck equipment. The utility model has the advantages of stable lifting, compact structure, flexible transportation, simple operation, small semi diameter of rotation, etc. It is used for cargo handling and stacking in factories, workshops, warehouses, stations, docks, etc. It is more suitable for those sites with fire and explosion protection requirements (such as printing workshops, oil depots, docks, warehouses, etc.). If it is combined with pallet containers, containers, etc., it can achieve unit transportation, effectively reducing collision, scratches and stacking area of parts, reducing handling workload, and improving handling efficiency.
Product Description
1. The fork can be adjusted according to the actual production situation.
2. The rubber-coated handle ensures comfortable and easy operation of the machine.
3. Reasonable structure, easy to carry.
4. Foot pedal, easy and labor-saving
5. The lifting is stable, the descending speed is controllable, and there is no impact when descending with full load.
6. Provide a variety of wheel options and assemblies, which can be customized according to actual needs.
7. The gantry is integrally formed with channel steel, fully automatic welding to increase the strength and prevent deformation.
8.Whole casting hydraulic pump, beautiful appearance, strong and durable.
We can customize the color, wheel and foot pedal according to the customer's needs.
Wheel customization
The wheels are available in three types: nylon, rubber and PU, which can be selected according to the use position of the Buyer; Rubber wheels are suitable for smoking or rough floors, quiet and durable. Nylon, low resistance, suitable for food processing, chemical industry and fishery; PU, wear-resistant, traceless, quiet and durable.
Specifications：
|
Model |
CTY-A 2.0 |
|
Capacity(kg) |
2000 |
|
Lower height of forks(mm) |
85 |
|
Fork lift height (mm) |
1600 |
|
Fork length (mm) |
900 |
|
Fork adjustable width (mm) |
250～580 |
|
Gantry material |
14#Universal Beam |
|
Fork material |
12#Channel steel |
|
Lifting speed (mm/s) |
14 |
|
Descent speed(mm/s) |
controllable |
|
Width(mm) |
760 |
|
Minimum refueling amount(L) |
2 |
|
Front wheel size (mm) |
φ85×50 |
|
Rear wheel size (mm) |
φ180×50 |
|
Overall size (mm) |
1440×760×2050 |
If you are interested in the product, contact 2bvideo.com for more information for more information
