Automatic Glazed tile Roof Sheet Making Machine
An automatic glazed tile roof sheet making machine is a type of industrial equipment that is used to produce glazed tiles for roofing purposes. The machine is designed to automate the process of producing glazed tiles by using advanced technology such as computer control systems, hydraulic systems, and other mechanical systems.
The machine is typically composed of several components, including a decoiler, a feeding system, a roll forming machine, a cutting system, a control system, and a hydraulic system. The decoiler is used to unwind the raw material, which is typically a coil of steel or aluminum. The feeding system then guides the raw material into the roll forming machine, which shapes the material into the desired profile.
Technical details
|
Description |
|
|
Usage |
Construction Building Material |
|
Production Capacity |
10~12m/min |
|
Power |
5.5kw |
|
Weight |
3.5T |
|
Voltage |
380V |
|
Supply Ability |
8 Set/Sets per Month |
|
Uncoiler Dimensions |
1700mm*1000mm*800mm |
|
Width of feeding |
300mm |
|
Capability |
3Ton |
|
Ring of expand(by manual) |
420mm—510mm |
|
Feeding entrance table-guide |
adjustable |
|
Entrance width range |
100-250mm |
|
Entrance and guide roller |
diameter is ￠65mm, material is sae1045, HRC48-52° surface with chrome |
|
cutting system Hydraulic power |
3KW |
|
Hydraulic working pressure |
10Mpa |
|
Material of blade |
Cr12 with heat treatment 58-60°2 sets cutter |
|
Length measuring |
Automatic encoder length measuring |
|
Output table frame |
welding by tube |
|
Diameter of rollers |
55mm |
|
Supporter roller |
ASTM 1045 with chrome |
|
Date of delivery |
40 days |
|
Payment method |
30% advance charge，70% pay off on delivery |
